Estimation of Electric Vehicle Battery Ohmic Resistance Using Dual Extend Kalman Filter

Abstract:

Using the traditional measurement analysis methods to estimate electric vehicle lithium ion battery ohmic resistance, it is difficult to realize on line. We in this paper use dual extend kalman filter (DEKF) based on thevenin model to solve this problem. DEKF is a kind of circulative iteration algorithm of two kalman filters, applied in the estimation which the systems state and parameter both are unknown. Using DEKF on the estimation of battery ohmic resistance only need the battery current and terminal voltage, therefore, it can be realized on line easily. This paper verified the effectiveness of DEKF through simulation and analysis of the test data.

• Periodical: Applied Mechanics and Materials (Volume 391)
• Pages: 246-249
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.391.246
• Online since: September 2013
• Authors: Qiao Yan Chen, Ke Xin Wei
• Keywords: Battery Model, Dual Extend Kalman Filter (DEKF), Electric Vehicle (EV), Ohmic Resistance

References

[1] ABRAHAMA D P, LINA J, CHENA C H, et al. Diagnosis of power fade mechanisms in high-power lithium-ion cells[J]. Journal of Power Sources, 2003, 119-121: 511-516.

DOI: 10.1016/s0378-7753(03)00275-1

[2] KHARE N, CHANDRA S, GOVIL R. Statistical modeling of SOH of an automotive battery for online Indication[C]/Proc of IEEE 34th International Telecommunications Energy Conference. P.O. Banasthali: IEEE Press, 2008: 1-7.

DOI: 10.1109/intlec.2008.4664086

[3] SCHMIDTA A P, BITZERB M, IMRE A W, et al. Model-based distinction and quantification of capacity loss and rate capability fade in Li-ion batteries[J]. Journal of Power Sources, 2010, 195(22): 7634-7638.

DOI: 10.1016/j.jpowsour.2010.06.011

[4] HUET F. A review of impedance measurements for determination of the state-of-charge or state-of-health of secondary batteries[J]. Journal of Power Sources, 1998, 70(1): 59-69.

DOI: 10.1016/s0378-7753(97)02665-7

[5] REMMLINGER J, BUCHHOLZ M, MEILER M, et al. State-of-health monitoring of lithium-ion batteries in electric vehicles by on-board internal resistance estimation[J]. Journal of Power Sources, 2001, 196(12): 5357-5363.

DOI: 10.1016/j.jpowsour.2010.08.035

[6] KIM I A. Technique for estimating the state of health of lithium batteries through a dual-sliding-mode observer[J]. IEEE Transactions on Power Electronics, 2010, 25(4): 1013-1022.

DOI: 10.1109/tpel.2009.2034966

[7] ABRAHAMA D P, KNUTH J L, DEES D W, et al. Performance degradation of high-power lithium-ion cells-electrochemistry of harvested electrodes[J]. Journal of Power Sources, 2007, 170(2): 465-475.

DOI: 10.1016/j.jpowsour.2007.03.071

[8] KARDEN E, BULLER S, DE DONCKER R D. A method for measurement and interpretation of impedance spectra for industrial batteries[J]. Journal of Power Sources, 2000, 85(1): 72–78.

DOI: 10.1016/s0378-7753(99)00385-7

[9] SINGHA P, VINJAMURIA R, WANG X, et al. Fuzzy logic modeling of EIS measurements on lithium-ion batteries[J]. Electrochimica Acta, 2006, 51(8-9): 1673–1679.

DOI: 10.1016/j.electacta.2005.02.143

[10] TAKENO K, ICHIMURA M, TAKANO K, et al. Quick testing of batteries in lithium-ion battery packs with impedance-measuring technology[J]. Journal of Power Sources, 2004, 128(1): 67–75.

DOI: 10.1016/j.jpowsour.2003.09.045
