Nonlinear Dynamics of Peak-Current-Controlled Superbuck Converter

Abstract:

Superbuck converter is a high-order converter, which has the unique advantage of the continuous input current, but increases the complexity of nonlinear phenomena of the system. This paper applies sample-data model to analyze the nonlinear dynamics of Superbuck converter with peak current control. The Jacobian matrix of the sample-data model is acquired to analyze the stability of the converter. On the other hand, the bifurcation analysis is carried out with the reference current as a bifurcation parameter based on the sample-data model. Several representative waveforms are captured from simulation, which verify the analytical results.

• Periodical: Applied Mechanics and Materials (Volume 392)
• Pages: 446-449
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.392.446
• Online since: September 2013
• Authors: Chuang Bi, Yong Xiang, Qian Zhang, Hua Lu
• Keywords: Peak Current Control, Period-Doubling Bifurcation, Stability, Superbuck Converter

References

[1] C. K. Tse, S. C. Fung and M. W. Kwan: IEEE Trans. on Circuits Syst. I, Vol. 43 (1996), p.605.

[2] C. K. Tse, Y. M. Lai and H. H. -C. Iu: IEEE Trans. on Circuits Syst. I, Vol. 47 (2000), p.448.

[3] A. Kavitha, G. Indira and G. Uma: IEEE Industry Applications Society Annual Meeting, p.1 ( 2008).

[4] M. Karppanen, J. Arminen, T. Suntio, K. Savela and J. Simola: IEEE Trans. on Power Electron., Vol. 23 (2008), p.1370.

DOI: 10.1109/tpel.2008.921080

[5] T. Sammaljarvi, F. Lakhdari, M. Karppanen and T. Suntio: IET Power Electron., Vol. 1 (2008), p.527.

[6] T. Suntio, J. Leppäaho, J. Huusari and L. Nousiainen: IEEE Trans. on Power Electron., Vol. 25 (2010), p.2409.

[7] W. Ma, M. Wang and C. Li: Nonlinear Dynamics, Vol. 67 (2012), p.2573.
