Contactless OLTC Technology Based on Inductive Load

Abstract:

This paper studies the fast On-Load Tap Changer (OLTC) technology of contactless switch without transition resistance or transition reactor. It not only provides the equivalent circuit of OLTC, the impact current calculation formula and the OLTC simulation waveform based on the inductive load but also supplies with the main electrical circuit and the waveform recorded in the experiments. The MJN3 contactless voltage-controlled power source has been developed with MCT801D intelligent module, which can accomplish to rapidly switch in voltage-controlled gears based on the inductive load. Its output current is continuous with no impact, no over-voltage and voltage-drop, which can achieve the high performance and high reliability.

• Periodical: Applied Mechanics and Materials (Volume 392)
• Pages: 484-488
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.392.484
• Online since: September 2013
• Authors: Jin Long Tu, Cai Xia Pan
• Keywords: On-Load Tap Changer (OLTC), Simulation, Transformer, Waveform

References

[1] D. Rogers and T. Green: Method and apparatus for performing on-load mechanical switching operations, UK patent 0916190. 2, (2009).

[2] Y. L. Zhao, S. T. Dong, and X. G. Yang: Study on Non Contract Automatic On-Load Voltage Regulating Distributing Transformer Based on Solid Relay, in Conference Proceedings IEEE IPEMC2006, Shanghai China, vol. 1, pp.484-488.

DOI: 10.1109/ipemc.2006.4778031

[3] X. M. Li, W. Q. Wang, and S. C. Zhang, et al: Arcless and Fast Response OLTC Model and its Simulation, High Voltage Engineering, vol. 2(2006), pp.24-26.

[4] Y.H. Chung, G.H. Kwon, T.B. Park, et al: Dynamic voltage regulator with solid state switched tap changer, Quality and Security of Electric Power Delivery Systems, 2003. CIGRE/PES 2003, GRE/IEEE PES InternationalSymposium, pp.105-108.

DOI: 10.1109/qsepds.2003.159804

[5] J. Faiz, B. Siahkolah, New solid-state, onload tap-changers topology for distribution transformers. IEEE Transactions on Power Delivery, vol. 1(2003), pp.136-141.

DOI: 10.1109/tpwrd.2002.803723

[6] K. Abbaszadeh， M. Ardebili， A. R. Alae: Design and Built of on-Load Fully Electronic Tap-Changer with Triac Switch: Simulation and Practical Results, IEEE 1st Power Electronic Driver Systerms Tech Conference, (2010), pp.330-334.

DOI: 10.1109/pedstc.2010.5471794

[7] Y. X. Yu, C. S. Wang: Theories and Methods on Stability of Power Systems, Beijing: Science Press, (1999).

[8] S. X. Zhou, L. Z. Zhu, X. J. Guo, et al: Power System Voltage Stability and Control, Beijing: China Electric Power Press, (2004).

[9] G. L. Wang: A survey on effect of on-load tap changer on the voltage stability, Relay, (2008), pp.79-84.

[10] CAI Bo, CUI Xue-shen, CHEN Xiao: Research of Non-Impact Current in Transient Process of Contactless On-Load Voltage Regulation, Electrotechnics Electric, vol. 1(2010), pp.1-4.

[11] Y. Q. Weng and J. L. Tu: Non-contact voltage regulating transformer lighting energy saving device, State Intellectual Property Office of the People's Republic of China. Patent No. ZL200810021102. 6, (2012).

[12] J. L. Tu, M. W. Tang, and Y. X. Li: The New Exploration for Transformer with OLTC, Conference on Smart Grid and Advanced electric power equipments & CES society intelligence system and application, (2011), pp.23-28.
