Modeling and Simulation of Doubly-Fed Wind Power Generators Based on PSCAD/EMTDC

Abstract:

This paper builds the mathematical model of a doubly-fed wind power generator (DFIG) which is widely used in wind power generation. Based on stator magnetic field orientation vector technique, active and reactive power decoupling control strategy is constructed. Based on the software package PSCAD/EMTDC, the grid-connected system of DFIG is modeled, and the dynamic response characteristics of generators active and reactive power on ramp change of wind speed conditions is simulated and analyzed. The simulation results show that the variable pitch DFIG has good operating characteristics and the model is correct.

• Periodical: Applied Mechanics and Materials (Volume 392)
• Pages: 475-479
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.392.475
• Online since: September 2013
• Authors: Le Wang, Lin Guan, Xin Ming Fan
• Keywords: Double Fed Induction Generation (DFIG), Modeling, PSCAD/EMTDC, Simulation

References

[1] Wang Changgui, Cui Rongqiang. New energy generation technology. Beijing: China Power Press, (2003).

[2] J.G. Slootweg, H. Polinder, W.L. Kling. Initialization of wind turbine models in power system dynamics simulations, 2001 IEEE Porto Power Tech Conference.

DOI: 10.1109/ptc.2001.964827

[3] Cui Zhihong, Zheng Yuan, Zuo Lu, Zhang Dehu. Wind power generation control technology. Beijing: China Water Conservancy and Hydropower Press, (2010).

[4] R. Pena, RJ.C. Clare, G. M . Asher. Doubly Fed Induction Generator Using Back-to-back PWM Converters and Its Application to Variable Speed Wind Energy Generation. IEEE Proceeding on Electrical Power Applications, 1996, pp.231-241.

DOI: 10.1049/ip-epa:19960288

[5] Zhao Dongli, Guo Jindong, Xu Honghua. Variable Speed Constant Frequency Doubly-fed Wind Power Generator Active and Reactive Power Decoupling Control Research and Implementation, Solar Energy Academic Journal, 2006, pp.174-179.

DOI: 10.1007/978-3-540-75997-3_462
