Analysis of Soot Particle Movement in Diesel Engine under the Influence of Drag Force

Abstract:

The formation of soot is influenced by the composition of air entrainment and structure of hydrocarbon in the fuel. Soot will then form during combustion in a diesel engine. Some of the soot particles will be released from the engine through the exhaust nozzle and some will stick to the cylinder walls. The soot that sticks to the cylinder wall can affect the lifetime of the lubricant oil. Subsequently this will decrease the durability of the diesel engine. By understanding the movement of the soot particles, the effect to the engine can be decreased. Therefore, the initial position and last position of soot particle was recognized through this study. The data for the formation of soot particles in the diesel engine was obtained from previous investigation. The study of soot movement at 8° crankshaft angle under the influence of drag force with different radial, axial and angular settings were carried out using a MATLAB routine. The results showed that the movement of soot particle will change with different parameter settings. Besides that, comparison of the results of soot particle movement influenced by drag force and without drag force has been carried out. It was observed that drag force caused shorter soot particle movement path and moves them away from the cylinder wall.

• Periodical: Applied Mechanics and Materials (Volume 393)
• Pages: 275-280
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.393.275
• Online since: September 2013
• Authors: Mohd Hafidzal Mohd Hanafi, Faizal W.M. Wan Mohd, A. Roslizar, Mohamad Shukri Zakaria, Mohd Noor Asril Saadun, Abdul Rafeq Saleman
• Keywords: After Top Dead Center (ATDC), Crankshaft, KIVA-3V, Lubricant Oil, Soot

References

[1] A.N. Shah, G. Yun-shan, T. Jian-wei, Carbonyls emission comparison of a turbocharged diesel engine fuelled with diesel, biodiesel, and biodieselediesel blend, Jordan Journal of Mechanical and Industrial Engineering 3 (2) (2009) 111e118.

[2] A.A. Abdel-Rahman, On the emissions from internal-combustion engines: a review, International Journal of Energy Research 22 (1998) 483e513.

[3] S. Lebedevas, A. Vaicekauskas, Research into the application of biodiesel in the transport sector of Lithuania, Transport 21 (2) (2006) 80e87.

DOI: 10.3846/16484142.2006.9638047

[4] I. Sezer, Thermodynamic, performance and emission investigation of a diesel engine running on dimethyl ether and diethyl ether, International Journal of Thermal Sciences 50 (2011) 1594e1603.

DOI: 10.1016/j.ijthermalsci.2011.03.021

[5] S. George, S. Balla, M. Gautam, Effect of diesel soot contaminated oil on engine wear, Wear 262 (2007) 1113–1122.

DOI: 10.1016/j.wear.2006.11.002

[6] Mahmood, W. M. F. W. 2011. Computational Studies of Soot Paths to Cylinder Wall Layers of a Direct Injection Diesel Engine. Phd Tesis Department of Mechanical, Materials and Manufacturing Engineering, The University of Nottingham.

[7] F. Bonatesta, A. La Rocca, P.J. Shayler, E. Wahab, The Influence of Swirl Ratio on Soot Quantity and Distribution in the Cylinder of a Diesel Engine, Third European Combustion Meeting ECM (2007).

[8] Shayler, P.J., Ng., H.K., Simulation studies of the effect of fuel injection pattern on NO and soot formation in diesel engines. SAE Papers, 2004(2004-01-0116).

DOI: 10.4271/2004-01-0116

[9] Shayler, P.J., Brooks, T.D., Pugh, G.J. and Gambril, R. , The Influence of Pilot and Split-Main Injection Parameters on Diesel Emissions and Fuel Consumption. SAE Papers, 2005(2005-01-0375).

DOI: 10.4271/2005-01-0375

[10] K. Boussouara and M. Kadja, Numerical investigation of soot formation in diesel jet flame with KIVA-3V, Revue des Energies Renouvelables Vol. 12 N°1 (2009) 55 – 62.

[11] Hiroyasu, H., and Nishida, K., Simplified Three-dimensional Modeling of Mixture Formation and Combustion in a D.I. Diesel Engine. SAE Papers, 1989(890269).

DOI: 10.4271/890269

[12] Nagle, J., and Strickland-Constable, R.F. Oxidation of Carbon Between 1000-2000°C. in Proc of the Fifth Conf. On Carbon. 1962. Pennsylvalnia State University, University Park, Pennsylvania: Pergamon Press.

DOI: 10.1016/b978-0-08-009707-7.50026-1

[13] Hong, S., Wooldridge, M.S., Im, H.G., Assanis, D.N. and Pitsch, H., Development and application of a comprehensive soot model for 3D CFD reacting flow studies in a diesel engine. Combustion and Flame, 2005. 143: pp.11-26.

DOI: 10.1016/j.combustflame.2005.04.007

[14] Suhre, B.R., Foster, D.E. 1992. In-cylinder soot deposition rates due to thermophoresis in a direct injection diesel engine. SAE Papers, (921629).

DOI: 10.4271/921629

[15] M, Eduardo, P, Thiago, F, Fernando , 2009, An extended analysis for the dynamic of soot particle in droplet combustion, 20th International Congress of Mechanical Engineering.

[16] Rosner, D.E., Mackowski, D.W., Garcia-Ybarra, P., 1991, Size - and Structure - Insensitivity of the Thermophoretic Transport of Aggregated Soot Particles in Gases, Combustion Science and Technology, Vol. 80, pp.87-101.

DOI: 10.1080/00102209108951778
