Numerical and Experimental Impact Analysis of Square Crash Box Structure with Holes

Abstract:

Numerical and experimental study of the effects of center holes located at opposite sides on dynamic axial crushing of thin-walled square aluminum extrusions column are presented in this paper. The results showed that, by inserting the holes, the impact energy absorption characteristic in a progressive buckling can be improved as the starting location of the plastic deformation is always from holes and peak crush force can be decrease, so that the deceleration does not exceed the limit that can injure the passenger when frontal impact occurs. Here, the results of numerical simulations, conducted using an explicit finite element code, are compared with experimental results for various hole diameter. The results shows that the peak crushing force is decrease, while the mean crushing force is relatively constant.

• Periodical: Applied Mechanics and Materials (Volume 393)
• Pages: 447-452
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.393.447
• Online since: September 2013
• Authors: Tatacipta Dirgantara, Leonardo Gunawan, Ichsan Setya Putra, Sahril Afandi Sitompul, Annisa Jusuf
• Keywords: Axial Crushing, Crashworthiness, Impact, Thin-Walled Structure

References

[1] J. Reid. Crashworthiness of automotive steel mid-rails: Thickness and material sensitivity. Thin-Walled Structures: 26(2): 83-103, (1996).

DOI: 10.1016/0263-8231(96)00010-9

[2] S.P. Santosa and T. Wierzbicki. Crash Behaviour of Box Columns Filled with Aluminum Honeycomb or Foam. Computers and Structures: 343-367, (1998).

DOI: 10.1016/s0045-7949(98)00067-4

[3] C. Kindervater. Aircraft and helicopter crashworthiness: Design and simulation. In Ambrosio, J.A.C., Pereira, M.F.O.S. & Silva, F.P. (eds), Crashworthiness of Transportation System.

DOI: 10.1007/978-94-011-5796-4_20

[4] J. Simon and S. Kirkpatrick. High-speed passenger train crashworthiness and occupant survivability. In E. Chirwa & D. Viano (eds), International Crashworthiness Conference, Woodhead Publishing Limited, pp.216-226, (1998).

DOI: 10.1533/cras.1999.0095

[5] I.S. Putra, T. Dirgantara, L.H. Anh, H. Homma, K. Kishimoto. Behaviour of Thin Walled Square Tube and Tubular Hat Sections Subjected to Low Velocity Impact Loading. Advanced Materials Research: Vols. 33-37, pp.387-394, (2008).

DOI: 10.4028/www.scientific.net/amr.33-37.387

[6] Annisa Jusuf, Fajri Syah Allam, Tatacipta Dirgantara, Leonardo Gunawan, Ichsan Setya Putra. Low Velocity Impact Analyses of Prismatic Columns using Finite Element Method. Key Engineering Materials, Vols. 462-463, pp.1308-1313, (2011).

DOI: 10.4028/www.scientific.net/kem.462-463.1308

[7] S.S. Hendradjaja, L. Gunawan, T. Dirgantara, I. S Putra. NumericalParametric Study for Prismatic Columns Subjected To Low Velocity Impact Loading. Proceeding of Regional Conference on Mechanical and Aerospace Technology (RCMEAE) 2010, p.533 – 539.

[8] I. Wirayudhia, S. Sindhu, A. Jusuf, T. Dirgantara, L. Gunawan, I.S. Putra. Impact Analysis of Thin-Walled Prismatic Columns. Proceeding of The International Conference on Advances in Mechanical Engineering (ICAME), (2009).

[9] M. Mora, A. Jusuf, T. Dirgantara, L. Gunawan, I.S. Putra. Low Velocity Impact Analysis of Foam-Filled Double-Walled Prismatic Columns. Proceeding of The International Conference on Advances in Mechanical Engineering (ICAME), (2009).

DOI: 10.4028/www.scientific.net/kem.462-463.1308

[10] Leonardo Gunawan, Tatacipta Dirgantara, Ichsan Setya Putra. Development of a Dropped Weight Impact Testing Machine. International Journal of Engineering and Technology IJET–IJENS, Vol. 11: 06, 120–126, (2011).

[11] Annisa Jusuf, Tatacipta Dirgantara, Leonardo Gunawan, Ichsan Setya Putra. Numerical and Experimental Study of Single-Walled and Double-Walled Columns under Dynamic Axial Crushing. Journal of Mechanical Engineering, Vol. 9, No. 2, (2012).

[12] Tatacipta Dirgantara, Leonardo Gunawan, Ichsan Setya Putra, Sahril Afandi Sitompul, Annisa Jusuf. Analysis of Square Crash Box Structure with Hole Due To Impact Loading. Proceeding of The Regional Conference on Mechanical and Aerospace Engineering (RCMEAE), (2013).

DOI: 10.4028/www.scientific.net/amm.393.447
