Application of Wavelet Analysis in Blade Faults Diagnosis for Multi-Stages Rotor System

Abstract:

Blade fault is one of the most common faults in turbomachinery. In this article, a rotor system which consists of multiple stages of blades was developed. A variety of blade fault conditions were investigated and its vibration responses were measured. The feasibility of wavelet analysis for multi-stages blade fault diagnosis was tested using simulated signals as well as experimental data. The use of wavelet analysis as the tool to detect multi stages blade faults was studied. Some probable solutions to improve multi stages blade fault diagnosis by wavelet analysis were also suggested.

• Periodical: Applied Mechanics and Materials (Volume 393)
• Pages: 959-964
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.393.959
• Online since: September 2013
• Authors: Ahmed M. Abdelrhman, M. Salman Leong, Lim Meng Hee, Wai Keng Ngui
• Keywords: Blade Fault Diagnosis, Multi Stage Blade System, Wavelet Analysis

References

[1] Meher-Homji, C. B, Blading Vibration and Failures in Gas Turbines: Part B, Compressor and Turbine Airfoil Distress, ASME, 1995, Paper no. 95-GT-419.

DOI: 10.1115/95-gt-419

[2] A.M. Abdelrhman, M.S. Leong, S.A.M. Saeed, and S.M. Al Obiadi, A Review of Vibration Monitoring as a Diagnostic Tool for Turbine Blade Faults, Applied Mechanics and Materials, 2012, 229: pp.1459-1463.

DOI: 10.4028/www.scientific.net/amm.229-231.1459

[3] M. Salman Leong, Field Experiences of Gas Turbines Vibrations -A Review and Case Studies, Journal of System Design and Dynamics, 2008, Vol. 2, No. 1, pp.24-35.

DOI: 10.1299/jsdd.2.24

[4] Simmons, H. R, A Non-Intrusive Method for Detecting HP Blade Resonance, ASME, 1986, Paper No. 86-JPGC-Pwr-36.

[5] Simmons, H. R, Non-Intrusive Detection of Turbine Blade Resonance, Third EPRI Conference on Incipient Failure Detection in Power Plants, Philadelphia, (1987).

[6] Parge, P., Trevillion, B., Carle, P, Machinery Interactive Display and Analysis System Description and Applications, Proceedings of the First International Machinery Monitoring and Diagnostic Conference, Sept 11-14, 1989, Las Vegas, Nevada. Pp. 176-182.

[7] Parge, P, Non-Intrusive Vibration Monitoring for Turbine Blade Reliability, Proceedings of Second International Machinery Monitoring and Diagnostic Conference, Oct 22-25, 1990, Los Angeles, California. Pp. 435- 446.

[8] Lim Meng Hee and M. Salman Leong. Diagnosis for Loose Blades in Gas Turbines Using Wavelet Analysis, Journal of Engineering for Gas Turbines and Power, vol. 127, 2005, p.314.

DOI: 10.1115/1.1772406

[9] Y. Lu, F. Meng, and Y. Li, Research on Rub Impact Fault Diagnosis Method of Rotating Machinery Based on Wavelet Packet and Support Vector Machine, International Conference on Measuring Technology and Mechatronics Automation. 2009, pp.707-710.

DOI: 10.1109/icmtma.2009.539

[10] Mathioudakis, K., Loukis, E, Papailiou, K. D, Casing Vibration and Gas Turbine Operating Conditions, ASME Journal of Engineering for Gas Turbine and Power, 1990, Vol. 112. Pp. 478-485.

DOI: 10.1115/1.2906192

[11] Baines, N, Modern Vibration Analysis in Condition Monitoring, Noise and Vibration Control Worldwide, May 1987, Pp. 148-151.

[12] Lim Meng Hee, Application Of Wavelet Transform Analysis For The Diagnosis Of Blade Faults In Rotating Machinery, PhD Thesis, Universti Technologi Malaysia, (2010).

[13] TSE, P W T and YANG, W X, A New Wavelet Transform for Eliminating Problems Usually Occurring in Conventional Wavelet Transform Used for Fault Diagnosis, Proceedings of the 9th International Congress on Sound and Vibration (ICSV9), No 465, Orlando, USA, 8-11 July 2002, paper no 465.

[14] Yan, Z., A. Miyamoto, and Z. Jiang, Frequency slice wavelet transform for transient vibration response analysis, Mechanical Systems and Signal Processing, 2009, 23(5): pp.1474-1489.

DOI: 10.1016/j.ymssp.2009.01.008

[15] Peng, Z.K., F.L. Chu, and P.W. Tse, Detection of the rubbing-caused impacts for rotor stator fault diagnosis using reassigned scalogram, Mechanical Systems and Signal Processing, 2005. 19(2): pp.391-409.

DOI: 10.1016/j.ymssp.2003.09.007
