Analysis of Multi-Directional Squeeze Casting Liquid Forging of Sewing Machine Oil Chassis

Abstract:

Sewing machine oil chassis is manufactured by adopting the method of multi-directional squeeze casting liquid forging. When multi-directional pressure is applied on the template, forward and radial pressures inside the solidified body are the same at each direction according to calculation and analysis. The internal pressure inside the blanks is the same, and crystal growth rate and plastic deformation are consistent at each direction, therefore solidification tissue conformation of the cast during multi-directional squeeze casting liquid forging eliminates the defects of directional difference, uneven density, even looseness, cavity shrinkage and the like.

• Periodical: Applied Mechanics and Materials (Volumes 397-400)
• Pages: 87-90
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.397-400.87
• Online since: September 2013
• Authors: Cai Ling Xu
• Keywords: Even, Internal Tissue, Liquid Forging, Multi- Directional Squeezing

References

[1] Xu Cailing, Patent; Multi-directional Squeeze Casting Liquid Forging Forming Process Method; Application No. 201320119865. 0; In Chinese.

[2] J.O. Aweda, M.B. Adeyemi. Experimental determination of heat transfer coefficients during squeeze casting of aluminium [J]. Journal of Materials Processing Technology. 2009, 209: 1477~1483.

DOI: 10.1016/j.jmatprotec.2008.03.071

[3] J.O. Aweda, M.B. Adeyemi. Determination of temperature distribution in squeeze cast aluminium using the semi-empirical equations' method [J]. Journal of Materials Processing Technology, 2009, 209(17).

DOI: 10.1016/j.jmatprotec.2009.06.005

[4] A. Boschetto, G. Costanza, F. Quadrini. Cooling rate inference in aluminum alloy squeeze casting [J]. Materials Letters., 2009, 61: 2969~2972.

DOI: 10.1016/j.matlet.2006.10.048

[5] Xu Cailing, Analysis of Single-axis Squeeze Casting Solidification Morphology and Plastic Deformation Defect: Special Casting & Nonferrous Alloys [J] In Chinese 2011 Vol 31, 05.

[6] ShouQie Lou, BingGuang Chen, Pixiang Qi. Liquid Forging and Squeeze Casting Technique [M]．Beijing: Chemical Industry Press, In Chinese 2006：12~31.
