Study on a New Type Gas Regulator Based on Dual-Mode Self-Tuning PID Control

Abstract:

The stable output-pressure of a gas regulator has important significance to the operational safety. This new intelligent gas regulator’s key problem is that the output-pressure is difficult to be stable with the single PID control parameters as the initial parameters. For this reason, a Dual-Mode Self-Tuning PID controller is designed, the controller can adjust the Kp, Ki, Kd with different initial value at the different workplace. After simulating with the MATLAB and AMESIM .We find it improves the dynamic property and stable-state property in the natural gas output system effectively. There are practical significance and theoretical reference for the improvement of non-linear industrial control system dynamic behavior.

• Periodical: Applied Mechanics and Materials (Volumes 40-41)
• Pages: 40-45
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.40-41.40
• Online since: November 2010
• Authors: Jun Gong Ma, Yue Xue Liu, Guo Chang Bai
• Keywords: AMEsim, Dual-Mode Self-Tuning PID Control, Gas Regulator, MATLAB, Pressure Control

References

[1] Shafiei Z, Shenton A T, Tuning of PID-type controllers for stable and unstable systems with time delay, Automatica, 1994, 30(10), p.1610–1615.

DOI: 10.1016/0005-1098(94)90100-7

[2] Silva G J, Datta A, Bhattacharyya S P, New results on the synthesis of PID controllers, IEEE Trans on Automatic Control, 2002, 47(2), p.241–252.

DOI: 10.1109/9.983352

[3] DASGUPTA K, KARMAKAR R. Modeling and dynamics of single-stage pressure relief valve with directional damping[J]. Simulation Modeling Practice and Theory, 2002, 10(1): 51-67.

DOI: 10.1016/s1569-190x(02)00059-x

[4] MISRA A, BEHDINANB K, CLEGHORNAI W L. Self-excited vibration of a control valve due to Fluid-structure interaction[J]. Journal of Fluids and Structures, 2003, 16(5): 649-665.

DOI: 10.1006/jfls.2002.0441

[5] Omstoph Kuert , Mazcel Jufer, Yves Perriard. New Method for Dynamic Modeling of Hybrid Stepping Motors , 0-7803-7420-7/02 [J]. IEEE (2002).

DOI: 10.1109/ias.2002.1044060

[6] Huang C T, Lin Y S, Tuning PID controller for open-loop unstable process with time delay , Ind Eng. Chen Res, 1995, 133, p, 11-30.

DOI: 10.1080/00986449508936309

[7] WANG Q G, LEE T H, FUNG H W, PID tuning for improved performance, IEEE Trans on Control Systems Technologe, 1999, 7(4), pp.457-765.

[8] Y. Zhu, B.D. Chen, and B. Zhang, Comparison between the experimental units for natural gas hydrate, Natural Gas And Oil, vol. 22, no 4, pp.25-27, 2004. (in Chinese).

[9] WONG Pak-kin, TAM Lap-mou, LI Ke, Dynamic model and simulation on a novel electro-hydraulic fully variable valve system for four-stroke automotive engines[J]. Chinese Journal of Mechanical Engineering , 2007, 20, 20(5): 80-86.

DOI: 10.3901/cjme.2007.05.080
