Analysis and Solution on the Correlation between Dissolved Oxygen Sensor and pH Sensor for Water Quality Monitoring

Abstract:

This paper designs a multi parameter real-time water quality on-line monitoring system for aquaculture water. This system achieves the online monitoring among temperature, turbidity, DO (dissolved oxygen), pH and electrical conductivity. The crosstalk, produced by the simultaneous measurement with DO and pH sensors, will affect accuracy and stability of monitoring results. This paper analyzes the source of crosstalk, describes a circuit model of causing crosstalk, and designs an isolated circuit between powers and signals as well. The experimental results show that, the real-time monitoring of DO and pH has the characteristics of speediness, high precision, small error and low noise.

• Periodical: Applied Mechanics and Materials (Volumes 411-414)
• Pages: 1445-1450
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.411-414.1445
• Online since: September 2013
• Authors: Li Ya Liu, Dean Zhao, Yun Qin
• Keywords: Crosstalk, Dissolved Oxygen (DO), Isolation, pH, Water Quality On-Line Monitoring

References

[1] Huiwen Jia, Guangbin Cao, Shuyi Jiang. Automatic Control Water Parameters of the Fish Recirculating Culture[J]. Chinese Journal of Fisheries, 2010(in Chinese).

[2] Xingguo Liu, Zhaopu Liu, Pengxiang Wang. Aquaculture security guarantee system based on water quality monitoring and its application[J]. Transactions of the Chinese Society of Agricultural Engineering, 2009(in Chinese).

[3] Guoming Qian, Songyou Wu. Online Examination of Water Quality and Its Application in Agriculture[J]. Chinese Agricultural Mechanization, 2008(in Chinese).

[4] Qisheng Ding, Daokun Ma, Daoling Li. RESEARCH AND APPLICATION ON COMPENSATION AND CALIBRATION METHODS FOR SMART SENSOR OF DISSOLVED OXYGEN[J]. Journal of Shandong Agricultural University(Natural Science Edition), 2011(in Chinese).

[5] Mariolakos,I., et al., 2007. Real-time monitoring on Evrotas River (Laconia, Greece): dissolved oxygen as a critical parameter for environmental status classification and warning. Desalination 213, 72–80.

DOI: 10.1016/j.desal.2006.05.056

[6] Guicheng Wang et al. Design of intelligent acidity measure instrument[J]. Chinese Journal of Scientific Instrument, 2006(in Chinese).

[7] Tai, Haijiang, I., et al., Design of an intelligent PH sensor for aquaculture industry. Computer and Computing Technologies in Agriculture IV 347, 642–649.

[8] Deliang Li et al. TEMPORAL AND SPATIAL DISTRIBUTIONAL PATTERNS OF MOLLUSCA IN A TYPICAL AQUACULTURAL LAKE -DATONG LAKE[J]. Acta Hydrobiologica Sinica, 2011(in Chinese).

[9] Sichun Bai et al. The Isolation-measurement Technology Based on the Linear Optocoupler for EPS Voltage[J]. Instrumentation Technology, 2010(in Chinese).
