A Separation Technology for Biological Radar Signals of Respiration and Heartbeat

Abstract:

This research aimed to separate the signals of respiration and heartbeat effectively from the biological radar echo signals of vital signs detecting platform. Therefore the characteristics parameters of the respiration and heartbeat could be extracted to provide the basis for clinical diagnosis and disease prevention. This paper put forward a separation algorithm of heartbeat and respiration based on LMS adaptive harmonic cancellation, the combined harmonics of the breathing signal was regarded as a reference input signal of the adaptive filter to improve the algorithm. Related experiments were designed to conduct filter processing. Results show that the algorithm proposed proved to be more effective in the signals separation of respiration and heartbeat.

• Periodical: Applied Mechanics and Materials (Volumes 411-414)
• Pages: 1564-1568
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.411-414.1564
• Online since: September 2013
• Authors: Hua Zhang, Sheng Li, Xi Jing Jing, Yang Zhang, Teng Jiao, Peng Fei Zhang, Hao Lv, Xiao Yu, Hui Jun Xue, Guo Hua Lu, Jian Qi Wang
• Keywords: Adaptive Noise Cancellation, Biological Radar, Least Mean Square (LMS)

References

[1] Lu Guohua, Wang Jianqi, and Jing Xijing et al. The research status of the biological radar technology. Foreign Medical Sciences Biomedical Engineering Fascicle. 27 (6): 368-383(2004) (In Chinese).

[2] Alexander M. Vergara, Victor M. Lubecke. Data Acquisition System for Doppler Radar Vital Vital-Sign Monitor[C]. Conference of the IEEE EMBS. Lyon: August, 2269-2272(2007).

DOI: 10.1109/iembs.2007.4352777

[3] Dung Nguyen, Shuhei Yamada, Byung-Kwon Park. Noise Considerations for Remote Detection of Life Signs with Microwave Doppler Radar[C]. Conference of the IEEE EMBS. Lyon: August, 1667-1670(2007).

[4] Igor Immoreev, Teh-Ho Tao. UWB Radar for Patient Monitoring[J]. IEEE Areospace and Electronic Systems Magazine, 27(8): 11-18(2008).

DOI: 10.1109/maes.2008.4693985

[5] Yanming Xiao, Jenshan Lin. et. al. A Ka-Band Low Power Doppler Radar System for Remote Detection of Cardiopulmonary Motion [J]. Engineering in Medicine and Biology Society, 2005. IEEE-EMBS 2005. 27th Annual International Conference of the Digital Object Identifier, 5: 7151-7154(2005).

DOI: 10.1109/iembs.2005.1616156

[6] Dennis R. Morgan and Michael G. Zierdt. Novel Signal Processing Techn -iques for Doppler Radar[J]. Signal Processing, 89 pp.45-66(2009).

DOI: 10.1016/j.sigpro.2008.07.008

[7] Wang Haibin, Ni Ansheng, and Wang Jianqi et al. The de-noising application of LMS algorithm in the non-contact signal detection of life parameters. Chinese Journal of Medical Instrumentation. 27 (1): 368-383(2003) (In Chinese).

[8] Yue Yu. The separation technology of breathing and heartbeat signals in the biological radar detection technology. Master's Thesis , The Fourth Military Medical University. 52-56(2007) (In Chinese).

[9] PAULO S.R. DINIZ. The adaptive filtering algorithm and its realization, translated by Liu Yulin, Jing Xiaojun, Tan Gangbin et al. Beijing: Publishing House of Electronics Industry, 121-135(2004).
