Optimal PI Controller Tuning Based on ITAE Criterion for Low-Order Systems with Large Time Delay

Abstract:

For low order process with large time delay, a kind of optimal PI controller tuning method is proposed based on generalized Hermite-Biehler theorem and Genetic Algorithm. Firstly, the stable region of PI controller is obtained by using the generalized Hermite-Biehler theorem. Then the optimum parameters are selected from this region based on ITAE criterion and genetic algorithm. A tuning formula is obtained by nonlinear fitting of optimization result, which has the capability to cover the variety of normalized time delays up to 100. Simulation of Monte-Carlo stochastic experiment indicates that the proposed method has good performance robustness when parameter uncertainty occurs, compared with other four PI tuning methods.

• Periodical: Applied Mechanics and Materials (Volumes 411-414)
• Pages: 1716-1719
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.411-414.1716
• Online since: September 2013
• Authors: Feng Ping Pan, Hong Kai Liao, Jia Luo, Xi Zhang
• Keywords: Hermite-Biehler Theorem, ITAE Criterion, Monte-Carlo Method, Optimal Pi Control

References

[1] M. Zhuang, D.P. Atherton: IEE Proc. -D Vol. 140(1993), p.216.

[2] D.E. Seborg, T.F. Edgar, D.A. Mellichamp: Process dynamics and control (Wiley, New York 1989).

[3] G.K.I. Mann, B.G. Hu and R.G. Gosine: IEE Proc. Control Theory Appl Vol 148(2001), p.251.

[4] Feng Xu: Research on Robust Controller and its application in Control of Thermal Plants (Thesis, Tsinghua University, Beijing 2002).

[5] A. Datta, M.T. Ho, S.P. Bhattacharyya: Structure and Synthesis of PID Controllers (Springer, London 2000).

[6] Y.L. Xue, D.H. Li, F. Xu, C.D. Lv: J T singhua U niv (Sci & Tech) Vol. 44 (2004), p.1067.

[7] B.Z. Khan, B. Lehman: IEEE Trans. Vol. 4 (1996), P. 459.
