Design and Research on Online Sampling Device of New Cigarette Making Machine

Abstract:

The paper introduces the structure and design principles of online sampling device of a new high-speed cigarette machine. The device is an important part of C2 cigarette online sampling and measurement system, it gets samples from the high-speed cigarette maker machine's conveiying line and send samples to C2 measuring instrument for testing, and it achieved the goal of automatic on-line monitoring of cigarette physical parameters. The device has compact structure and expediently installation, which makes it not only replace manual sampling of high-speed cigarette making machine, but also detect and display various physical parameters of cigarette in real time.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 931-935
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.931
• Online since: September 2013
• Authors: Wei Ying, Guang Bin Yi, Yi Zhou
• Keywords: C2 Cigarette Integrated Test Stand, High-Speed Cigarette Making Machine, Online Sampling Device

References

[1] Wang Yuguang, Zhang Li, Wang Jun, Si Rulin, Application of C2 cigarettes to online detection instrument [J], Microcomputer Information, 2009, 25(12): 92-93.

[2] Wang Shien, Liang Jieshen, Automatic detection of physical parameters and control system design [J], Sensor and Microcomputer, 2011, 30 (2): 104-106.

[3] Wang Lihong, Step motor travel control based on PLC [J], Modular Machine Tool and Automatic Processing Technology, 2008, 11: 44-45.

[4] Wang Lihong, Zhao Yueling, Yang Zhongwen, Study on speed control methods of step motor based on PLC [J], Journal of Liaoning University Of Technology (Natural Science), 2010, 30(4): 215-217.

[5] Lu Yunhua, Graphic appliances and PLC control technology [M], Beijing: Mechanical Press, 2011: 60-70.
