Design of 3-D Functional Characteristic Parameters of Rolling Interface Measurement System

Abstract:

The current two-dimensional (2-D) parameters for surface assessment (R_a and P_c) could not actually reflect functional properties of bearing and lubricant retention capabilities of steel sheets and rolls surface. Based on ARM9 development board, this paper has been working on secondary development of M1 mobile surface roughness meter, creating a model of calculating three-dimensional (3-D) functional characteristic parameters with 2-D profiles, and optimizing influence factors with Genetic Algorithms (GA). By comparing with measurement results by white-light interfering profile meter, the measurement error of the developed system is within10%, which was proved to be practical in the factory.

You might also be interested in these eBooks

Recent Trends in Materials and Mechanical Engineering II

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 420)

Pages:

56-61

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.420.56

Citation:

Cite this paper

Online since:

September 2013

Authors:

Dong Xu, Jie Zhang, Hong Bo Li, Jin Song Lu, Qing Guo Fan, Hai Long Dong

Keywords:

3D, Cold Rolling, Measurement System, Parameter, Surface Topography
