Development of Electrolyte Vacuum Surface-Boiling Electrodeposition Apparatus

Abstract:

With the electrolyte in the vicinity of cathode surface being boiling, electrolyte vacuum surface-boiling electrodeposition is a kind of novel electrodeposition technology implemented in a vacuum environment. The development of its apparatus faces more design challenges in comparison with the ones served for the conventional electrodeposition techniques. To development this special epectrodeposition apparatus, two kinds of systems, namely, electrolyte circulation and filtration system driven by film-pressure and gravity, and condensation-collection-backflow system, were come up with, and their details were introduced in this paper. The applications show that the apparatu can meet the requirements of laboratory research and industrial production very well.

• Periodical: Applied Mechanics and Materials (Volumes 423-426)
• Pages: 2006-2009
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.423-426.2006
• Online since: September 2013
• Authors: Ping Mei Ming, Wen Xing Lv, Jing Yu Shang, Jun Tao Wang, Qiao Lin Hao
• Keywords: Circulation and Filtration System, Condensation-Collection-Backflow System, Electrodeposition Apparatus, Vacuum

References

[1] D. Li: Electrochemistry Theory (BUAA Publication, China, 2008). (in Chinese).

[2] W. Schwarzacher: Interface Vol. 15 (2006),P. 32.

[3] M. E. Hyde and R.G. Compton: J. Electroanal. Chem. Vol. 531(2002),P. 19.

[4] J. S. Chen, Y. H. Huang and Z.D. Liu: Nonferrous Met. Soc. China Vol. 15(2005),P. 247.

[5] Z.W. Zhu, D. Zhu and N.S. Qu: Sci. Sinica Technol. Vol. 38(2008),P. 1529.

[6] L. Pessel: U.S. Patent 2, 465, 747. (1949).

[7] S.M. Bloom, A. Hoffman and K.S. Norland: U.S. Patent 4, 193, 847. (1978).

[8] E. Muttilainen and T. Korpi: Mat. Design Vol. 5(1984),P. 126.

[9] D. Zhu: CN Patent 91108101. 1. (1997).

[10] J.W. Dini, T.G. Beat and W.C. Cowden: AESF SUR/FIN'92, 1992,P. 883.

[11] S.E. Nam, S. H Lee and K.H. Lee: J. Membr. Sci. Vol. 153(1999),P. 163.

[12] P.M. Ming, D. Zhu and Y.Y. Hu: Acta Armamentarii Vol. 29(2008),P. 746.

[13] P.M. Ming, W.J. Jiang and J.X. Zheng: CN Patent 201010198012. 1. (2010).

[14] P. M. Ming, Y.J. Li and S. Q. Wang: Surf. Coatings Technol. Vol. 213(2012),P. 299.

[15] T. H. Tsai, H. Yang and R. Chein: Microsys. Technol. Vol. 10(2004),P. 351.

[16] Z. C. Guo, Y. P. Gong, and W. C. Lu: Science in China Series E: Technol. Sci. Vol. 50(2007),P. 39.

[17] P.M. Ming, J.Y. Shang and Z.B. Yang: CN Patent 201210308530. 3. (2012).

[18] P.M. Ming W.X. Lv and J.Y. Shang: CN Patent 201320275502. 6. (2013).
