Study on Different Connection Types of Air Spring

Abstract:

Three accurate dynamic model of air spring was set up through aerodynamics, fluid mechanics, structural mechanics,engineering thermodynamics, etc. According to the new established bellow-orifice-reservoir model, bellow-pipe-reservoir model and bellow-orifice-pipe-reservoir model, the dynamic characteristics of air spring were calculated under different excitation amplitudes and frequencies. By comparison with experimental results, it shows that the simulation results of the three models and experimental results coincide very well in dynamic characteristics; the bellow-orifice-pipe-reservoir connection type is recommended as the secondary suspension for low frequency excitations; and the bellow-orifice-reservoir connection type is considered effectively for high frequency excitations; the bellow-pipe-reservoir connection type is not recommended to be used as the secondary suspension because of its negative stiffness.

• Periodical: Applied Mechanics and Materials (Volumes 423-426)
• Pages: 2026-2034
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.423-426.2026
• Online since: September 2013
• Authors: Hong Xing Gao, Mao Ru Chi, Min Hao Zhu, Ping Bo Wu
• Keywords: Air Spring, Connection Types, Modeling, Orifice, Pipe

References

[1] Junmao Yan: Vehicle Engineering (China Railway Press, China 1999).

[2] K. Shimazawa and T. Tohtake: Quarterly Report of RTRI Vol. 49 (2008), pp.209-214.

[3] Mingjun Zheng, Xiaokai Chen and Lin Yi: Transactions of the Chinese Society for Agricultural Machinery Vol. 39 (2008), pp.10-14. (In Chinese).

[4] N. Docquier, P. Fisette and H. Jeanmart: Vehicle System Dynamics Vol. 45 (2007), pp.505-524.

DOI: 10.1080/00423110601050848

[5] N. Docquier, P. Fisette and H. Jeanmart: Vehicle System Dynamics Vol. 46 (2008), pp.481-493.

DOI: 10.1080/00423110801993110

[6] N. Docquier, A. Poncelt, M. Delannoy and P. Fisette: submitted to Vehicle System Dynamic (2010).

[7] M. Berg: A Three-dimensional Airspring Model with Friction and Orifice Damping, in: Proceedings at the 16th IAVSD Symposium on Dynamics of Vehicles on Roads and Tracks, Pretoria, South Africa (1999).

DOI: 10.1201/9781003210924-44

[8] A. Facchinetti, L. Mazzola, S. Alfi and S. Bruni: Mathematical Modelling of Railway Vehicles with Secondary Airspring Suspension: Safety and Ride Comfort, in: Proceedings at the 21th IAVSD Symposium on Dynamics of Vehicles on Roads and Tracks, Stockholm, Sweden (2009).

DOI: 10.1080/00423114.2010.486036

[9] J. Grajnert and O. Krettek: ZEV+DET Vol. 115 (1991), pp.352-359.

[10] Xingjuan Ying, Haolin Li, Zhengji Ni: University of Shanghai for Science and Technology Vol. 28 (2006), pp.164-168. (In Chinese).

[11] Yanchun Zhong, Qingjun Yang, Gang Bao: Journal of Central South University Vol. 42 (2011), pp.3754-3759. (In Chinese).
