Study on the Recycling Machine of Plastic Film with Shovel-Excavation Screening

Abstract:

In order to solve the problems that the current components using for recycling the film in the Plastic film recycling machine are not suitable for a large quantity of coating stubble corn plastic film recycling. Based on the work principle of “shovel-excavation screening”, developing the whole design:shovel film stubble→topsoil delivery→soil sieve→set the heap surface.By optimizing the design and combination of various components to achieve plastic film recycling of corn stubble. This machine can meet the requirements of recycling the film, raising the stubble and grounds care in the alpine arid regions. It can solve the difficult problems about the uneasy recovery of the serious damage film and the film recycling of the stubble crops like corn.The experiment showed:①The plastic film recycling on topsoil can use the way of shoveling, in the first step all the film was picked up from the topsoil.②At the same time it can be able to recycle the film containing 22.5% corn stubble.③ The plastic film recovery on the topsoil can reach or over 90%.

• Periodical: Applied Mechanics and Materials (Volumes 423-426)
• Pages: 2045-2048
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.423-426.2045
• Online since: September 2013
• Authors: Ying Chao Liu, Jian Ming Jian, Ying Ding Chen, Shu Lin Hou
• Keywords: Hestubble Stubble of the Corn, Plastic Recycling Machine, Recyclingthe Film and Raising the Stubble, Shovel-Excavation Screening

References

[1] Shulin Hou.: Transactions of the Chinese Society of Agriculture Engineering(2002)(In Chinese).

[2] Shulin Hou, Zhihuai Mao, Jianming Kong: Journal of China Agriculture University(2002)(In Chinese).

[3] Shulin Hou, Huiyou Zhang: Journal of Agricultural Mechanization Research(1998)(In Chinese).

[4] Jing Xu, in : Mechanical Design Handbook, Beijing Industry Press, Beijing(2001). (In Chinese).

[5] Cz. Kanamycin Voith Chomsky (Poland), in: Harvesting machinery, translated by Chongwen Cao, Chunjiang Wu, China Agricultural Machinery Press, Beijing(1983)(In Chinese).

[6] Zhenjiang Agricultural Machinery Institute, Jilin University of Technology, eds. in: Theory and design of agricultural machinery, China Industry Press, Beijing(1961)(In Chinese).

[7] Department of Agricultural, Agricultural Machinery Institute of Science and Technology , in: Agricultural Machinery Design Reference Manual, Machinery Industry Press, Beijing(1960)(In Chinese).

[8] Chinese Academy of Agricultural Mechanization Sciences, in: Agricultural Machinery Design Handbook, Machinery Industry Press, Beijing(1990)(In Chinese).

[9] C. Llop, A. Pérez. Issue Macromolecular Symposia(1992).

[10] Kaiqin Zhou, in: Mechanical Parts Manual, Higher Education Press, Beijing(2006)(In Chinese).
