Design of a Voltage-Controlled Beam Scanning Antenna Array Based on CRLH TL

Abstract:

The voltage-controlled beam scanning antenna array based on the CRLH transmission line is designed with series power divider and three small antenna. The resonant frequency of the open-termination power divider is 2.5GHz, and the varactor bias voltage of the small antenna is from 8V to 2V. At the operating frequency of 2.5GHz, the horizontally polarized pattern of the antenna array is measured. When the bias voltage of the varactor is changed, the antenna array radiation beam scanning range is up to 96 degrees, and its radiation from backward to forward can be achieved by controlling the varactor bias voltage.

• Periodical: Applied Mechanics and Materials (Volumes 427-429)
• Pages: 628-631
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.427-429.628
• Online since: September 2013
• Authors: Rui Kun Wu*, Guo Tai Chen
• Keywords: Antenna Array, Beam Scanning, Composite Right/Left Transmission Line, Polarization Pattern

References

[1] Cui Wanzhao, Ma Wei, Qiu Lede, et al. Electromagnetic Metamaterials and its applications [M]. Beijing: National Defense Industry Press, 2008: 4-16.

[2] D. R. Smith, D. C. Vier, Willie Padilla, et al. Loop-wire medium for investigating plasmons at microwave frequencies [J]. Applied Physics Letters, 1999, 75(10): 1425-1427.

DOI: 10.1063/1.124714

[3] C. Caloz, H. Okabe, T. Iwai, et al. Transmission line approach of left-handed (LH) materials [C]. USNC/URSI National Radio Science Meeting, San Antonio, TX, 2002, 39: 39-41.

[4] C. Caloz, T. Itoh. Application of the transmission line theory of left-handed (LH) materials to the realization of a microstrip LH line, [C]. IEEE Ante. Prop. Soci. Int. Symp. 2002, vol. 2: 412-415.

DOI: 10.1109/aps.2002.1016111

[5] C. Caloz, T. Itoh, et al. Transmission line approach of left-handed (LH) materials and microstrip implementation of an artificial LH transmission line [J]. IEEE TRANSACTIONS ON ANTENNAS AND PROPAGATION, 2004, vol. 52: 1159-1166.

DOI: 10.1109/tap.2004.827249

[6] L. Lei, C. Caloz, T. Itoh. Dominant mode leaky wave antenna with backfire-to-endfire scanning capability [J], Electron. Lett., 2002, vol. 38: 1414-1416.

DOI: 10.1049/el:20020977

[7] Wu Ruikun. Investigation of Radiation Characteristics for Metamaterial Microstrip Leaky-Wave Antennas [J]. Journal of Microwaves, 2011, 27(1): 44-47.

[8] C. Caloz, A. Sanada, and T. Itoh. A novel composite right/left-handed coupled-line directional coupler with arbitrary coupling level and broad bandwidth [J]. IEEE Trans. Microwave Theory Tech., 2004, vol. 52: 980-992.

DOI: 10.1109/tmtt.2004.823579

[9] Zhang Yewen, Li Guiquan, He Li, et al. One-Dimensional Metamaterial-Based Microstrip Leaky-Wave Antenna with Backfire-to-Endfire Scanning Capability [J]. Journal of Tongji University(Natural Science), 2007, vol. 35: 811- 814.

[10] A. Lai, K. M. K. H. Leong, T. Itoh. A novel n-port series divider using infinite wavelength phenomena [C]. IEEE MTT-S International Microwave Symposium Digest, 2005: 1001- 1004.

DOI: 10.1109/mwsym.2005.1516834

[11] Ruikun Wu, Guotai Chen. Design of a 2. 5GHz Beam Antenna Array Controlled by Voltage Based on CRLH TL [C]. 2013 2nd International Conference on Computer Science and Electronics Engineering, 2013, vol. 32: 0402-0405.

DOI: 10.2991/iccsee.2013.103
