Dynamic Response of Conductor Breakage for Oxytropis Transmission Tower-Line System

Abstract:

Dynamic response of conductor breakage is analyzed on guyed oxytropis transmission tower-line system of 500KV 5291 JinJiang-Zhenjiang lines. Considering unbalanced tension, finite element method is presented. Result of the transient analysis shows that the vibration of tower-line system happens after conductor breakage. With the damping affect，the system vibration becomes gentle. For the tension of lines, the peak value of dynamic tension of conductor can be times of the initial tension. It is shown that the proposed method is of efficiency and practicality.

• Periodical: Applied Mechanics and Materials (Volume 43)
• Pages: 165-168
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.43.165
• Online since: December 2010
• Authors: Ran Li, Qiang Gao
• Keywords: Conductor Breakage, Dynamic Response, Oxytropis Transmission Tower-Line System

References

[1] McClure G, Lapointe M: Computers and Structures Vol. 81 (2003), p.825.

[2] Xia Zhengchun, Liang Zhengping, Li Li , Yi Peng: Journal of Wuhan University of Technology Vol. 3 (2008) , pp.84-88.

[3] Li Li , Xia Zhengchun , Jiang YichengLiang , Zhengping: Engineering Mechanics Vol. 25 (2006), pp.165-169.

[4] Li Renxian in: Basic knowledge of finite element. National Defence Industrial Press, China (2002).

[5] Liu Hongshi: Noise and Vibration Control. Vol. 6 (1999), p.21.

[6] Zhao Tianxiao in: The mechanics calculation of electrical wire on HV overhead transmission lines. China Electric Power Press, China (2003).
