Design of an Active Phase Conjugation Circuit for Retrodirective Array in UHF Band

Abstract:

An active phase conjugation circuit of retrodirective array which can be used in UHF band (890-960MHz) has been designed. Circuit of the retrodirective array consists of filters, mixers, dividers and other microwave devices. In this paper, microstrip filters and mixers are primarily designed. Divided matching circuit will be designed appropriate on the basis of the antenna element. Filters consist of microstrip coupled lines to conform with microstrip antenna arrays; to suppress the effect of RF input signals to output transmitted signals, selecting the image-rejection mixers. Simulation results of ADS show that all of the designed active devices display good performances.

• Periodical: Applied Mechanics and Materials (Volume 43)
• Pages: 201-206
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.43.201
• Online since: December 2010
• Authors: Xia Li Sun, Qing Zhang, Shu Yan
• Keywords: Filter, Mixers, Phase Conjugation, Retrodirective Array

References

[1] S. Lim, K.M.K.H. Leong, and T. Itoh: IEEE Transactions on Microwave Theory and Techniques Vol. 53(2005)No. 12, pp.3735-3743.

DOI: 10.1109/tmtt.2005.856086

[2] Sungjoon Lim and Tatsuo Itoh, in: 60-GHz Retrodirective Array System with Efficient Power Management, Proceedings of the 36th European Microwave Conference, P. 314-317.

DOI: 10.1109/eumc.2006.281319

[3] R.Y. Miyamoto: Microwave Sym-posium Digest, 2001 IEEE MTT-S Inter. Vol. 2 (2001) , pp.1119-1122.

[4] Ling Chen, Shu Yan: The Design of Retrodirective Array in Wireless Sensor Networks, 2009 International Conference on Networks Security, Wireless Communications and Trusted Computing, P. 219-222.

DOI: 10.1109/nswctc.2009.275

[5] Yanhua Chen, Zhaohui Li and Wei Xia: ADS Application Examples: RF Circuit Design and Simulation (People's Posts and Telecom Press, 2007), pp.287-306.

[6] Xinfu Xu: Simulation Examples of RF Circuit Design (ADS2008) (Publishing House of Electronics Industry, 2008 ) , P. 234-244.
