Investigation of Laser Marking Technology with the Image Mask of Liquid Crystal Display

Abstract:

In the laser marking process system, a liquid crystal display (LCD) was used as the image mask, which can display dynamically and flexibly the various images by the programmable control. A nanosecond pulsed laser (1064nm) was applied to investigate the characteristic of laser photolithography fabrication technology. The light modulation function of LCD mask was firstly discussed by theory. By observing the graphics morphology with a high-powered optical microscope, it was found that the graphics of laser marking with LCD mask shows that its edges were not ablated but its line inside was ablated. According to analysis, the reasons of this phenomenon are due to the opaque lattice effect and the high light transmittance of black pixel. Results showed that the light modulation function of LCD mask was decided by adjusting the light transmittance with controlling the pixel voltage and a complete graphics was ablated in the range of 0.6J/cm2 ~ 0.8J/cm2.

• Periodical: Applied Mechanics and Materials (Volume 43)
• Pages: 633-636
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.43.633
• Online since: December 2010
• Authors: Fei Chen, Zhao Yang Zhang, Yao Min Wang
• Keywords: Beam Modulation, Laser Marking, LCD Image Mask, Opaque Lattice Effect

References

[1] J. Qi, K.L. Wang, Y.M. Zhu：Journal of Materials Processing Technology vol. 139(2003), p.273.

[2] B. N. Chichkov, C. Momma, S. Nolte et al: Applied Physics A vol. 63(1996), p.109.

[3] J.J. Liu, Z.M. Wang, A.K. Li et al: Chinese Journal of Lasers vol. 34(2007), p.765.

[4] G. Oda, T. Miyoshi, Y. Takaya et al: Proceeding of Spire vol. 5662 (2004), p.649.

[5] H. X. Chen, Z. Sui, Z. P. Chen et al: Acta Optica Sinica vol. 9(2001), p.1107.

[6] T. Z. Shen, H. B. Lv, X. M. Qi, et al: Opto-Electronic Engineering vol. 31(2004), p.46.
