The Simulation Research of Damping Characteristics for the Underwater Vehicle Moving under or Exceeding Water

Abstract:

The vehicle may vibrate when it moves under or exceeding water. This vibration will interact with the flow filed around to form a fluid-structure interactiondynamics system. In this paper, the numerical simulation of a cylinder in the process of moving under or exceeding water with ABAQUS and FLUENT is presented. Simultaneously, the first three damping ratio of the system are obtained by damping identification. For different density, viscosity and velocity of water, model separately to get the impact of each factor. Besides, the continuous process of exceeding water has been discretized to obtaindifferent oscillating curvesat different positions with respect to the water,and then the change of the damping ratio is presented. Thus the damping characteristics of the system in the water-exit process have been obtained approximately.

• Periodical: Applied Mechanics and Materials (Volume 432)
• Pages: 281-287
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.432.281
• Online since: September 2013
• Authors: Chun Fang Zhang, Jing Bo Gao, Hai Bo Lü, Zhen Jun Zhao, Cong Wang
• Keywords: Cylinder, Fluid Structure Interaction (FSI), Hydrodynamic Damping, Numerical Simulation

References

[1] Wang zong-li, Jin zhan-li, Lin qi-rong, Liu zheng-xin. Numerical analysis of the influences of water depth on the vibration characteristics of submarine structures[J]. Journal of Mechanical Strength, 2001, 23（3）: 344~346.

[2] Ju gen-guo, Lv feng-wu, Wang bin. Random dynamic response analysis on steel-pipe pile construction platform based on wave force[J]. Journal of Railway Science and Engeering, 2006, 3(5): 70~74.

[3] Giles Thomas, Michael Davis, Damien Holloway, Tim Roberts. The vibratory damping of large high-speed catamarans[J]. Marine Structures 21 (2008) 1~22.

DOI: 10.1016/j.marstruc.2007.12.003

[4] J. R. Chaplin, K. Subbiah. Hydrodynamic damping of a cylinder in still water and in a transverse current[J]. Applied Ocean Research 20(1998): 251~259.

DOI: 10.1016/s0141-1187(98)00023-6

[5] J. R. Chaplin. Hydrodynamic damping of a cylinder at β≈106[J]. Journal of Fluids and Structures (2000) 14, 1101~1117.

DOI: 10.1006/jfls.2000.0318

[6] J. R. Chaplin, C. H. Retzler. Hydrodynamic damping of the vertical motion of a horizontal cylinder beneath waves at large scale[J]. Journal of Fluids and Structures (2001) 15, 929~940.

DOI: 10.1006/jfls.2001.0391

[7] Tikeswar Naik, Ellen K. Longmire, Susan C. Mantell. Dynamic response of a cantilever in liquidnear a solid wall[J]. Sensors and Actuators A 102 (2003) 240~254.

DOI: 10.1016/s0924-4247(02)00398-9

[8] Jean-Francois Sigrist, Stéphane Garreau. Dynamic analysis of fluid–structure interaction problems with modal methods using pressure-based fluid finite elements[J]. Finite Elements in Analysis and Design 43 (2007) 287 ~300.

DOI: 10.1016/j.finel.2006.10.002

[9] L. Lanoye, J. Vierendeels, P. Segers, P. Verdonck. Vascular fluid-structure-interaction using Fluent and Abaqus software [J]. Journal o f Biomechanics 2006, Vol. 39 (Suppl 1): 440.

DOI: 10.1016/s0021-9290(06)84797-4

[10] Yuan zhen-wei, Chu fu-lei, Wang san-Bao. Transverse vibration of the cylinder in the fluid dynamic characteristics[J]. Engineering Mechanics. 2006, 23（8）: 49-52.

[11] Morison J R, O'Brien M P, Johnson J W and Schaaf S A. The force exerted by surface wave on piles[J]. Petroleum Transactions, AIME, 1950, 189, 149-154.

DOI: 10.2118/950149-g

[12] Yuan ying-chun, Lai wei, Wang jun-jie, Hu shi-de. The effects of hydrodynamic damping on seismic response of bridge piles[J]. World Earthquake Engineering, 2005, 21（4）: 88~94.

[13] Qu nai-si, Guo yong-gang. Perturbation analysis of non-proportional dampig of dynamic water on platform structure[J]. MarineScience Bulletin, 1994, 13(6): 67~74.

[14] Yu yang, Zhou shu-xin. Added-mass and damping coefficients of a slender body under the influence of shallow water[J]. Journal of Dalian Maritime University, 1995, 21（1）: 51~55.
