An Industrial Robot Based Drilling System for Aircraft Structures

Abstract:

In order to realize automatic flexible drilling with high efficiency and good quality, a drilling system was established, which integrates the technology of laser measurement, off-line programming, computer control and robotics. In this system, the key coordinate frames are established by the laser tracker, the drilling programs are generated by the off-line programming and simulation system, the communication between the automatic drilling control system and the robot control system is based on the socket technique. By running drilling program, the moving platform, robot and the end effector can work automatically and harmoniously. In addition, the deviation compensation methods of hole position and its normal vector are proposed. The experimental results show that the efficiency of drilling can achieve 6 holes per minute, the position accuracy can be effectively controlled within 0.3mm, and the normal accuracy is better than 0.5°.

• Periodical: Applied Mechanics and Materials (Volumes 433-435)
• Pages: 151-157
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.433-435.151
• Online since: October 2013
• Authors: Yun Bo Bi, Yong Chao Li, Yi Hang Jiang, Jiang Xiong Li, Wei Wang, Mian Gao, Shuo Li
• Keywords: Automatic Drilling, Control System, Deviation Compensation, Robotics

References

[1] R DeVlieg, K Sitton, E Feikert, et al. ONCE (One Sided Cell End Effector) Robotic Drilling System[C]. In: SAE 2002 Automated Fastening Conference & Exhibition, Chester, ENGLA. SAE Technical Papers. 2002: 01-2626.

DOI: 10.4271/2002-01-2626

[2] R Devlieg, E Feikert. One-up assembly with robots[C]. In: SAE 2008 Aerospace Manufacturing and Automated Fastening Conference & Exhibition, North Charleston, SC, USA. SAE Technical Papers. 2008: 01-2297.

DOI: 10.4271/2008-01-2297

[3] J Atkinson, J Hartmann, S Jones, P Gleeson. Robotic drilling system for 737 Aileron[C]. In: SAE 2007 AeroTech Congress & Exhibition, Los Angeles, CA, USA. SAE Technical Papers. 2007: 01-3821.

DOI: 10.4271/2007-01-3821

[4] Weidong Zhu, Weiwei Qu, Lianghong Cao, et al. An off-line programming system for robotic drilling in aerospace manufacturing[J]. The International Journal of Advanced Manufacturing Technology, 2013: 1-11.

DOI: 10.1007/s00170-013-4873-5

[5] Information on http: /www. kuka. com.

[6] Qiang Zhan, Xiang Wang. Hand–eye calibration and positioning for a robot drilling system[J]. The International Journal of Advanced Manufacturing Technology, 2012, 61(5-8): 691-701.

DOI: 10.1007/s00170-011-3741-4

[7] Chunhong Zhao, Xiansheng Qin, Hong Tang. Research on open-CNC system based on PC[J]. Mech Sci Technol, 2005, 24(9): 1108-1113. (In Chinese).

[8] Shaohua Fei, Qiang Fang, et al. Countersink depth control of robot drilling based on pressure foot displacement compensation[J]. Journal of Zhejiang University. Engineering Science, 2012, 46(7).

[9] Yunlan Guan, Xiaojun Cheng, Guigang Shi. A robust method for fitting a plane to point clouds[J]. Journal of Tongji University (Natural Science), 2008, 7: 024. (In Chinese).
