A Novel Tilting Mechanism for Side Discharging Lorry

Abstract:

Side discharging lorry is widely used for the transportation of coal and gravels in the coal mine and the highway tunnel. Automatic, safe and efficient tilting mechanism is a challenge for side discharging lorry. Driven by hydraulic cylinders, the tilting mechanism of conventional side discharging lorry needs an additional equipment to coordinate its action,which makes the side discharging lorry more complex and increases the cost. Based on conventional tilting mechanism, a novel tilting mechanism was proposed. The control mechanism, mainly consisted of several connecting rods, can achieving sequential motions of the tilting mechanism. With actual working condition, a mechanism analysis was done to simulate working procedure of the mechanism. The simulation demonstrates the feasibility of proposed mechanical structure for side discharging lorry.

• Periodical: Applied Mechanics and Materials (Volumes 433-435)
• Pages: 201-204
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.433-435.201
• Online since: October 2013
• Authors: Peng Zhong Li*, Ran Ran Wang
• Keywords: Side Discharging Lorry, Simulation, Tilting Mechanism

References

[1] D.W. Liu and H.M. Chen: 2010 International Conference on Computational Intelligence and Vehicular System (Jeju, Korea, 22 November 2010). p.439.

[2] Chengli corporation on http: /www. clszqc. com/html/zixiechexilei/1071. html.

[3] X.Y. Liu, P.R. Zhao and F. Dai: Journal of Modern Transportation Vol. 19 (2011) No. 3, P 154.

[4] Q.L. Han, L.H. Tian and L.J. Qu: Computer Science and Information Technology (ICCSIT), 2010 3rd IEEE International Conference on (Chengdu, China, 9-11 July 2010) Vol. 9, p.745.

[5] J.C. Cheng, X.Y. DU, J.J. Shi, Y.L. Zhang and L. Fang: Journal of Central South University of Technology, Vol. 18 (2011) No. 2, p.587.

[6] D.T. Qin: Modern Mechanical Design Manual (In Chinese) (Chemical Industry Press, China, 2011).

[7] Information on http: /mechanicaldesign101. com/linkage-designs.

[8] J. Xie: Mechanical Principles (In Chinese) (Southwest Jiaotong University Press, China, 2010).

[9] X.T. Chen, J.H. Zhao: Computer-Aided Design and Computer Graphics, 2007 10th IEEE International Conference on (Beijing, China, 15-18 Oct. 2007). P. 258.

[10] C.X. Chen and Q.D. H: SolidWorks Motion Motion Simulation Tutorials (In Chinese) (China machine press, China, 2012).

[11] L.R. Wang, X.L. Yang: Proceedings of 2012 International Conference on Mechanical Engineering and Material Science (Shanghai, China, 28-30 December 2012). p.627.

[12] J.J. Fang: Mechanical Dynamic Simulation and Engineering Analysis (Chemical Industry Press, China, 2004).

[13] P.C. Zhu: Special Purpose Vehicle, 2006. P. 29.
