The System Research on Automatic Defect Detection of Glasses

Abstract:

A glasses defect inspection system is researched and developed according to the principle of light scattering and visual inspection method, which is based on the machine vision. In order to achieve the classification of glasses, the functions of image acquisition, simple image processing, grading and sorting of glasses are designed in this system. Operation of parallel structure is adopted in this system. Forwardlighting by low-angled-ring-LED is used to get the clear images of the defects in or on the surface of the glasses, such as speckles, impurities, feathers and so on. Image processing and glasses grading based on normalization algorithms are used to acquire the identifying information of various defects of glasses. Experiment results show that the detection system, which can detect all the kinds of defects of the glasses, has high processing speed and strong anti-interference capacity. The size of the smallest defect that can be detected by the system is 0.03mm, and the average detection time of each glass is less than 2s.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 362-365
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.362
• Online since: October 2013
• Authors: Hong Bing Yao, Jie Ping*, Gui Dian Ma, Liang Wan Li, Ji Nan Gu
• Keywords: Image Acquisition, Image Processing, Lens Defects, Machine Vision

References

[1] Xiong Guangjie, Ma Shuyuan, Wu Siyuan, et al., Design of new automatic optical inspection system of HID PCB, Computer Engineering and Design. 32 (2011) 3218-3221.

[2] Yu Bin-yang, Wang Zhao-ba, Jin Yong, Research on new method of glass-defect detection, Transducer and Microsystem Technologies. 27 (2008) 60-62.

[3] Hsu Quangcherng, Lin Chiming, Image-based inspection system for detection of glass substrate's edge defects, Applied Mechanics and Materials. 121 (2012)3970-3976.

DOI: 10.4028/www.scientific.net/amm.121-126.3970

[4] Jin Yong, Wang Zhao-ba, Zhu Lin-quan, et al., Study on glass defect inspection method based on out-of-plane moire, Journal of Computational Information System. (2012) 3921-3928.

[5] Tsai Meng-Tsan, Chang Feng-yu, Lee Ya-ju, et al., Defect detection and property evaluation of indium tin oxide conducting glass using optical coherence tomography, Optics Express. 19 (2011) 7559-7566.

DOI: 10.1364/oe.19.007559

[6] Konz loana, Fernandez Beatriz, Pereiro Rosario, et al., P, S and CI trace detection by laser ablation double-focusing sector field ICP-MS to identify local defects in coated glasses, Journal of Analytical Atomic Spectrometry. 26 (2011) 1526-1530.

DOI: 10.1039/c0ja00271b

[7] P. Lian, L. Xiaoming and C. Cheng, Based on embedded image processing technology of glass inspection system, Advances in Intelligent and Soft Computing. 128 (2011) 337-342.

[8] Amano Kazuki, Yoshimoto Shigeka, Miyatake Masaaki, et al., Basic investigation of noncontact transportation system for large TFT-LCD glass sheet used in CCD inspection section, Precision Engineering. 35 (2011) 58-64.

DOI: 10.1016/j.precisioneng.2010.08.010
