Development of Automotive Electronics HIL Simulation Experimental Platform

Abstract:

This paper presents a low-cost, simple and reliable solution for automotive electronics Hardware-In-Loop (HIL) simulation, taking Jetta AT1.6 car as object, designs and develops automotive electronics HIL simulation platform. Firstly, the overall structure of the platform is designed; secondly, system hardware platform is developed and built using Protel DXP; then, HIL simulation models of ABS (Anti-lock Braking System), engine and automatic transmission are built using Matlab/Simulink and develop automotive electronics HIL simulation platform; finally, carry on the experiment and the results show that the designed HIL simulation experimental platform is good. The platform has widespread applicability in the teaching experiments and the aspects of developing, debugging and testing of automotive electronics control systems.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 1893-1897
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.1893
• Online since: December 2010
• Authors: Jing Lian, Ya Fu Zhou, Teng Ma, Xiao Yong Shen
• Keywords: Automotive Electronics Control, HIL Simulation, Simulink
