Numerical Analysis of Exfoliation Corroded Holed Aluminum Plates Repaired with Adhesively Bonded Composite Patches

Abstract:

A 3D FE model of exfoliation corroded holed aluminum plates repaired with adhesively bonded composite patches was established in this paper, and then the stress distribution in the repaired aluminum plate was analyzed. The result shows after repairing in the exfoliation corroded holed aluminum plate gets reduced for 33.62%, and the repaired aluminum plates undergoes bending deformations due to the offset between load axis and centroidal axis of the repaired structure.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 2847-2851
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.2847
• Online since: December 2010
• Authors: Xiao Hua Yang, Ding Zhang, Lin Kuang, Yong Zhang, Wen Yong Ding
• Keywords: 3D FE Modeling, Composite Patch Adhesively Bonded Repair, Exfoliation Corrosion

References

[1] A. A. Baker: Applied Composite Materials Vol. 13 (2006), p.127–146.

[2] Naveen Rastogi, Som R. Soni, Jason J. Denney : Analysis of composite patch repaired metallic structures [R]. AIAA-98-1883.

[3] N. L. Post, J. Cain, K. J. McDonald, S. W. Case, J. J. Lesko: Engineering Fracture Mechanics Vol. 75 (2008), p.629–637.

[4] V. Sabelkin, S. Mall, M. A. Hansen, R. M. Vandawaker, M. Derriso: COMPOSITE STRUCTURES Vol. 79 (2007), p.55–66.

DOI: 10.1016/j.compstruct.2005.11.028

[5] H. Hosseini-Toudeshky: COMPOSITE STRUCTURES Vol. 76 (2006), p.243–251.

[6] Ki-Hyun Chung, Won-Ho Yang: COMPOSITE STRUCTURES Vol. 60 (2003), p.1–7.

[7] Gwo-Chung Tsai, Shyan Bob Shen: COMPOSITE STRUCTURES Vol. 64 (2004), p.79–90.

[8] Q. Y. Wang, M. R. Sriraman, N. Kawagoishi, Q. Chen: International Journal of Fatigue Vol. 28 (2006), p.1197–1201.

[9] D. Z. Yu, Y. L. Cheng, Q. H. Fan, Z. H. Jia, Y. Gao: Structure & Environment Engineering Vol. 37 No. 2 (2010), p.49–54, in Chinese.
