Study on Parameters for Affecting SCI of Sheet Metal Forming

Abstract:

The surface contact impression(SCI) is the neglected forming defect and seriously affects surface quality and mechanical property of stamping parts. The technology parameters and affective degree which alleviate or eliminate SCI are researched , four factors including die radius(DR) , die clearance(DC), punch radius(PR) and friction condition(FC) , which each factor chooses three levels are designed and constitute a L9（34）orthogonal table. The experimental results indicate that the significances order of technology parameters affecting SCI is DR> PR > DC >FC. The analyzed result shows that the superior parameter affecting SCI is DR ,the inferior is FC, adapted DC greatly removes SCI. the research puts forward a reference for improving surface quality of stamping parts.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 2862-2866
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.2862
• Online since: December 2010
• Authors: Ji Tao Du
• Keywords: Orthogonal Design of Experiment, Sheet Metal Forming, Surface Contact Impression, Technology Parameter

References

[1] Shanling He: Forging & Stamping Technology, , Vol. 24(1999), pp.47-50, in Chinese.

[2] Jitao Du. Study on Die Corner Radius and Clearance Affecting Surface Quality for U-Shaped Parts. Dissertation, University of Shanghai for Science and Technology, 2003, in Chinese.

[3] Miao Jin, Baofeng Guo, Shuoben Li, ect: Journal of Plasticity Engineering, Vol. 10(2003), pp.32-36, in Chinese.

[4] Zhongqin Lin, Gang Liu, Shuhui Li: Chinese Journal of Mechanical Engineering, Vol. 38(2002), pp.83-88, in Chinese.

[5] Yingke Hou, Weigang Zhang, Zhongqi Yu: Chinese Journal of Plasticity Engineering, Vol. 15(2008), pp.43-47, in Chinese.

[6] Jieshi Chen, Xianbin Zhou, Jun Chen: Journal of materials Processing Technology, Vol. 210(2010), pp.315-322.
