Optimized Processing Scheme for Abrasive Fault of Steam Turbine Shaft

Abstract:

It is of great significance to adopt the reasonable scheme to repair the abrasive shaft in order to make sure the safety and stable operation of the steam turbine unit. Taking a real 600MW steam turbine generator unit with worn shaft as the target system, we employ finite element software ANSYS to establish the model of the local worn shaft segment in this paper. Two kinds of optimized processing strategies are proposed to repair the worn shaft segment, considering the situation of cutting quantity and shear stress distribution. The two proposed schemes can reduce the stress concentration of the worn shaft parts largely. The study proves that the method is feasible and can be used to processing other similar failures.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 619-622
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.619
• Online since: December 2013
• Authors: Yu Jiong Gu, Jing Xu, Xi He
• Keywords: Abrasion, Finite Element Method (FEM), Shear Stress, Steam Turbine Shaft

References

[1] Rainer Kurz, Klaus Brun, Degradation of gas turbine performance in natural gas service, Journal of Natural Gas Science and Engineering. 1 (2009): 95-102.

DOI: 10.1016/j.jngse.2009.03.007

[2] Lei Yang, Maguang Pi, Liang Di, Zhiyuan Zhang, 660MW Supercritical Steam Turbine Rotor Wear and Treatment, Power System Engineering. 27 (2011): 57-61.

[3] Yujiong Gu, Safety analysis and application on torsional vibration of turbo-generator set, first ed., Science Press, Beijing, (2013).

[4] Darrell F. Socie, Fatigue-life prediction using local stress-strain concepts, Experimental Mechanics, 17 (1977): 50-56.

DOI: 10.1007/bf02326426

[5] Xucheng Wang, Finite element method, first ed., Tsinghua University Press, Beijing, (2003).
