The Out-of-Plane Stability Analysis of Crane Jib with Two Symmetric Drawbars

Abstract:

The out-of-plane stability of the crane jib with two symmetric drawbars is studied. Differential equation with two non-conservative forces caused by the two symmetric drawbars is established in critical condition. According to the boundary conditions and proper parameter processing, the out-of-plane characteristic equation is obtained for the crane jib. Comparison with the ANSYS results verified the correctness of the method. And special cases are given to show the consistency of the method used in this paper and that with one drawbar given by the Chinese Design Rules for crane (GB3811-2008). The contribution of the angle between two symmetric drawbars to the out-of-plane stability of the crane jib is also discussed. The results show that, the crane jib with two symmetric drawbars has higher out-of-plane stability than that with one drawbar, and the increase of the angle between the two symmetric drawbars will lead to the significant increase of the out-of-plane stability of the crane jib.

• Periodical: Applied Mechanics and Materials (Volumes 446-447)
• Pages: 469-473
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.446-447.469
• Online since: November 2013
• Authors: Nian Li Lu, Ce Chen, Shi Ming Liu
• Keywords: Characteristic Equation, Crane Jib, Non-Conservative Force, Out-of-Plane Stability, Two Symmetric Drawbars

References

[1] Shan Zenghai, Cao Lifeng, Jin Huiling, Cui Huapeng, YU Zhongtai: AKind ofCrane and It's Super-lift System[P]. Chinese Patant, 2011, 07.

[2] Teng Rumin, Yao Hairui, Chen Li, Long Zhiguo, Gao Shun-de: Study on Force Infection to The Arm Stand Caused by the Super-lift System of the All Terrain Crane[J]. Mechanical Design, 2012, 29(1): 92-96.

[3] Timoshenko SP, Gere JM: Theory of Elastic Stability[M]. 2nded. NewYork: McGraw-Hill, (1965).

[4] Lan Peng, Liu Manlan, Lu Nianli: Out-of-plane stability of Coupled Simply Supported Beams[J]. Eenineering Mechanical, 2005, 22: 152-155.

[5] Guoqiang Li, Jin Jun Li. A tapered Timoshenko–Euler beam element for analysis of steel portal frames[J]. Journal of Constructional Steel Research, 2002, 58(12): 1531~1544.

DOI: 10.1016/s0143-974x(02)00003-2

[6] Lu Nianli, Wang Jia, Lan Peng: Study on the Out-of-plane Stability of Bending Beam Under the Draft of Wire Cable [C]. 2010 International Conference on Digital Manufacturing and Automation, ICDMA 2010: 561-564.

DOI: 10.1109/icdma.2010.163

[7] Li YuMei The Out-of-plane Instability of a Bending Beam With Multiple Loads 2011 International Conference on Mechatronics and Intelligent Materials, MIM 2011: 930-934.

DOI: 10.4028/www.scientific.net/amr.211-212.930

[8] Ouyang Yu. Multi-parametric Space Beam Element in Stability Analysis of Frame Structures[J]. Journal of Huaqiao University(Natural Science), 1997, 18(4): 377~380. (in Chinese).

[9] Ouyang Yu. Elastic stability Analysis of Space Frame Structures[J]. Journal of Huaqiao University (Natural science), 1994, 15(3): 293~296. (in Chinese).

[10] Crane Design Standard GB3811-2008: 177~178.
