Research on the Inspection Information Extraction from 3D Models of Sheet Metal Parts by the Photoelectric Equipments

Abstract:

The short comings and limitations of traditional inspection method of sheet metal parts were described in this paper. Aiming at the inspection method based on the 3D models of sheet metal parts, the method of the inspection information extraction was introduced also. The actual shape of the sheet metal was obtained by the portable photoelectric equipments and then the 3D model was formed. The inspection information was extracted from the 3D model by the system which developed by VC++ tools on the CATIA platform. The characteristics of this method are high accuracy, environmental protection and high efficiency.

• Periodical: Applied Mechanics and Materials (Volumes 446-447)
• Pages: 486-490
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.446-447.486
• Online since: November 2013
• Authors: Li Wei Zhao, Dong Wang, Bo Hao, Li He
• Keywords: CATIA, Inspection Information Extraction, Photoelectric Equipments, Sheet Metal Parts
