Analysis of Losses and Thermal in Induction Motors

Abstract:

This paper presents an investigation into the losses and thermal characteristics of induction motors operated from pulse width-modulated (PWM) voltage supply in comparison to that operated from sinusoidal voltage supply. It was concluded that due to the abundant harmonics in the PWM waveforms, significant losses are induced in the motor by the inverter supply. The temperature ascends correspondingly. Experiments were conducted with no load and with load conditions. The losses and thermal characteristics were calculated using finite element analysis (FEA) and validated by the experiments.

• Periodical: Applied Mechanics and Materials (Volumes 446-447)
• Pages: 503-508
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.446-447.503
• Online since: November 2013
• Authors: Xiao Feng Ding, Hui Chang
• Keywords: Finite Element Method (FEM), Harmonics, Induction Motor (IM), Pulse Width-Modulated (PWM)
