Fault Location Method and Hardware Monitoring System of Parallel Compensating Capacitors

Abstract:

At present, the operational parallel compensating capacitors can only through the protection action for the information, so we cant location the fault capacitor. In order to obtain every parallel capacitor running status information and according to internal structure and the operation mode of film capacitor, this paper propose a method of locating a capacitor, and based on this method constructs a set of hardware monitoring system. This method can eliminate the affection caused by the environment and measurement error of sensor accuracy effectively and the hardware monitoring system can solve the insulation problem, which high-potential power supply and wireless collection and transmission technology bring.

• Periodical: Applied Mechanics and Materials (Volumes 448-453)
• Pages: 1977-1981
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.448-453.1977
• Online since: October 2013
• Authors: Yan Li, Lei Yang, Li Wei Zhu, Tao Zhao, Yun Peng Liu, Li Gao
• Keywords: Environmental Factors, Fault Location, On-Line Monitoring, Parallel Capacitor, Physical Model, Sensor

References

[1] Lu Anding: Power Station substation and power system reactive power ( China Electric Power Press, Beijing 2003). (In Chinese).

[2] Ni Xuefeng, Sheng Guozhao, Li Hao: Power Equipment, 2004(9): 10-13. (In Chinese).

[3] Xie Daohua: Capacitor performance and design (Standards Press of China, Beijing 1991). (In Chinese).

[4] Zhang Keming: Matrix theory and numerical analysis basis (China Electric Power Press, Beijing 2011). (In Chinese).

[5] Zhao Tao, Liu Yunpeng, Lv Fangcheng. A Feasibility and Method Research on the On-line Monitoring of Parallel Compensation Capacitors. Proceeding of CMD2012, Bali, Indonesia. 748-751.
