Finite Element Analysis on Frame of Rice Transplanting Mechanism at Different Operation Conditions

Abstract:

Frame is the basic component of rice transplanting mechanism, which needs sufficient strength and stiffness because the frame often endures heavy loads and hits on poor working conditions. The UG geometric model of design frame was imported into the ANSYS for meshing. Reasonable constraint conditions and load were imposed, and the most significant four operating conditions of the frame were analyzed though static method. The stress-strain contours of the frame were obtained. The analyzed result provides design theory for the new type frame of rice transplanting mechanism and reference for the rebuilding and optimizing of the frame structure.

• Periodical: Applied Mechanics and Materials (Volume 455)
• Pages: 202-206
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.455.202
• Online since: November 2013
• Authors: Chun Lan Mo, Wei Guan, Guan Yan Huang, Yong Juan Lu, Wen Zhong
• Keywords: Different Conditions, Finite Element, Frame, Stiffness

References

[1] LÜ Dongsheng, Wang Dongfang, Su Xiaoping. A static research of bus frame based on HYPERWORKS [J]. Machinery Design & Manufacture, 2011, (3): 11~12.

[2] Chen Yanhong, ZhuFeng. The Finite Element Analysis and The Optimization design of the Yj3128-type dump truck's sub-frames based on ANSYS[J]. Procedia Earth and Planetary Science, 2011, (2): 133~138.

DOI: 10.1016/j.proeps.2011.09.022

[3] Zhi Shuya, Liu Hongjun. Finite element analysis and optimizing design of the bus body[J]. Applied Mechanics and Materials, 2012: 78~81.

DOI: 10.4028/www.scientific.net/amm.215-216.78

[4] Zhao Ying, Zhang Ruihong, Xiao Suwei, et. 2ZG―6DK High-speed Transplanted chassis frame structure analysis and optimization [J]. Chinese Agricultural Mechanization, 244（6 ): 96~100.

[5] Yan Yue. Analysis of Bus Frame Based on ANSYS [J]. Journal of Liaoning University of Technology(Natural Science Edition), 2008, 28(6): 399~402.

[6] LI Dexin, LÜ Jiangtao, Ying Jinchun. The analysis of static and dynamic characteristic for SX360 type vehicle frame[J]. Mechanical Science and Technology for Aerospace Engineering, 2002, 21 ( 3) : 380-383, 386.

[7] Hadad, H, Ramezani. A Finite element model updating of a vehicle chassis frame[J]. Proceedings of the 2004 International Conference on Noise and Vibration Engineering, 2004: 1817-1831.

[8] Kichang Kim and Inho Choi. Design Optimization Analysis of Body Attachment for NVH Performance Improvements[C]. SAE technical paper series 2003-01-1604.

DOI: 10.4271/2003-01-1604
