The Calculation for Digging-Resistance of Small-Scale Excavator Based on Torque Method

Abstract:

The torque-based calculation model for digging-resistance of small-scale hydraulic excavator is presented. The simulation model of digging-resistance is built under AMESim environment, and the structural parameters of SWE50 excavator are imported into AMESim and the digging operation is simulated. The parameters gained from the simulation are imported into calculation model, then the correlation between calculation results and simulation results of digging-resistance is obtained, which shows that this calculation model can indicate effectively the dynamic process of resistance during digging operation and is better than the empirical formula. At last the digging-resistance experiment is operated and the actual resistance is calculated by use of experimental data. The calculation model is proved suitable further for analysis and application of the actual digging-resistance.

• Periodical: Applied Mechanics and Materials (Volume 456)
• Pages: 248-251
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.456.248
• Online since: October 2013
• Authors: Ji Lin He, Hai Hua Zheng*, Dong Li
• Keywords: Digging-Resistance, Experiment, Simulation, Small Hydraulic Excavator

References

[1] Lin X L, Di Y H: Small-scale excavator status, trends and strategies used[J]. Construction Machinery, 08 (2003), pp.38-41. (In Chinese).

[2] Single-bucket excavator[M]. Tongji University Press, (1986). (In Chinese).

[3] Wang J C, Li K X, Zhang H: The experimental research of excavator digging resistance[J]. Construction Machinery, 11(1992) , pp.21-47. (In Chinese).

[4] J. Maciejewski*, A. Jarzebowski: Laboratory optimization of the soil digging process[J]. Journal of Terramechanics, (2002) , p.161–179.

DOI: 10.1016/s0022-4898(02)00022-8

[5] S. Peth*, J. Rostek, et: Soil testing of dynamic deformation processes of arable soils[J]. Soil & Tillage Research, (2010) , p.317–328.

DOI: 10.1016/j.still.2009.10.007

[6] Allen Wilkinson*, Alfred DeGennaro: Digging and pushing lunar regolith: Classical soil mechanics and the forces needed for excavation and traction[J]. Journal of Terramechanics, (2007 ), p.133–152.

DOI: 10.1016/j.jterra.2006.09.001

[7] Sunghwan Jung, Amos G. Winter, A.E. Hosoi: Dynamics of digging in wet soil[J]. International Journal of Non-Linear Mechanics, (2011) , p.602–606.

DOI: 10.1016/j.ijnonlinmec.2010.11.007

[8] Kaspar Althoefer, et: Hybrid Soil Parameter Measurement and Estimation Scheme for Excavation Automation[J]. Transactions on instrumentation and measurement, 10 (2009) , pp.3633-3641.

DOI: 10.1109/tim.2009.2018699

[9] Peter I. Corke: Robotics Toolbox for Matlab. (2001) , pp.8-14.

[10] Saeed B. Niku: Introduction to Robotics: Analysis, Systems, and Application[M]. Pearson Education, (2001).
