Research on the Dynamics of the Double Helical Gear Transmission

Abstract:

Against the transmission characteristics of the double helical gear pair, considering the time-varying mesh stiffness, the bearing radial and axial stiffness, the tensile and compressive stiffness of the transmission shaft, the bending stiffness of that, error excitations, and corresponding dampings, a double helical gear pair bending-torsion-axis coupling dynamic model was established by using the lumped parameter method based on the gear meshing theory and Lagrange equations. Based on the model, the dynamic response of double helical gear pair was solved, and taking the right side of helical gear as an example, the frequency spectrum characteristics of dynamic meshing force of the right side of helical gear were mainly analyzed. This research establishes the foundation for dynamic performance optimizations and reliability designs of the double helical gear pair transmission system in the future.

• Periodical: Applied Mechanics and Materials (Volume 456)
• Pages: 256-259
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.456.256
• Online since: October 2013
• Authors: Fei Ren*, Da Tong Qin, Xiao Ling Wu
• Keywords: Double Helical Gear, Dynamic Characteristic, Dynamic Excitation, Dynamic Model

References

[1] S. Kumar et al: ASME Journal of Mechanisms, Transmissions and Automation in Design, Vol. 107 (1985) no. 1, pp.207-216.

[2] M. Benton, A. Seireg: ASME Journal of Mechanical Design, Vol. 102 (1982) no. 2, pp.450-463.

[3] A. Kahraman, G.W. Blankenship: Journal of Applied Mechanics, vol. 64 (1997) no. 1, pp.217-226.

[4] Y. Cai: ASME Journal of Mechanical Design, vol. 117 (1995) no. 9, pp.460-468.

[5] R.G. Parker, S.M. Vijayakar, T. Imajo: Journal of Sound and Vibration, vol. 237 (2000) no. 3, pp.435-455.
