Color Image Processing and Self-Localization for a Humanoid Soccer Robot

Abstract:

The paper proposed a series of image processing algorithm to recognize the evidences in an image accurately for humanoid soccer robot, such as color image segmentation based on HSV model, edge detection based on four linear operator, field straight line extraction by Hough transform based on 8-neighbhour connected domain clusters and identification of line intersection shape based on Hopfield network. Based on evidences from image processing, Piecewise Monte Carlo localization is presented to solve kidnap problem so that localization of humanoid robot can be not only adapt to rule changes for competition, but also be more efficient and robust. The effectiveness of the piecewise MCL is verified by RoboCup Adult Size humanoid soccer robot, Erectus. The experimental results showed that the humanoid robot was able to solve the kidnap problem adaptively with two strategies: resetting or revising, in which resetting was more efficient than revising gradually.

• Periodical: Applied Mechanics and Materials (Volume 461)
• Pages: 877-885
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.461.877
• Online since: November 2013
• Authors: Wei Hong, Yan Hui Zhang, Yan Tao Tian, Chang Jiu Zhou
• Keywords: Hopfield Network, Humanoid Soccer Robot, Kidnapped Problem

References

[1] Information on http: /www. tzi. de/humanoid/pub/Website/Downloads/HumanoidLeagueRules 2013_DRAFT_20130 422. pdf.

[2] Röfer. T, Jüngel. M., Vision-Based Fast and Reactive Monte-Carlo Localization, In: Proceedings of the IEEE International Conference on Robotics and Automation (ICRA-2003), Taipei, Taiwan, 856-861.

DOI: 10.1109/robot.2003.1241700

[3] Röfer, T., Jüngel, M , Fast and robust edge-based localization in the Sony four-legged robot league, In: 7th International Workshop on RoboCup 2003 (Robot World Cup Soccer Games and Conferences), Lecture Notes in Artificial Intelligence, Springer, in Erscheinen (2004).

DOI: 10.1007/978-3-540-25940-4_23

[4] Abdul Baist, Robert Sablatnig and Gregor Novak, Line-based Landmark Recognition for Self-localization of Soccer Robots, In: 2005 International Conference on Emerging Technologies, Islamabad, pp.132-137.

DOI: 10.1109/icet.2005.1558868

[5] A. Gasparri, S. Panzieri, F. Pascucci and G. Ulivi, Monte Carlo filter in mobile robotics localization: a clustered evolutionary point of view, Journal of Intelligent and Robotic Systems, vol. 47, no. 2(2006), pp.155-174.

DOI: 10.1007/s10846-006-9081-1

[6] S. Thrun, D. Fox, and W. Burgard, Monte Carlo localization with mixture proposal distribution, In Proc. of the 17th National Conf. on Artificial Intelligence and 12th Conf. on Innovative Application of Artificial Intelligence, (2000) pp.859-865.

DOI: 10.1016/s0004-3702(01)00069-8

[7] S. Thrun, D. Fox, W. Burgard, and F. Dellaert, Robust . Monte Carlo localization for mobile robots, Artificial Intelligence, vol. 128(1-2), pp.99-141, (2001).

DOI: 10.1016/s0004-3702(01)00069-8

[8] HongWei, Zhou Changjiu, Tian Yantao, Piecewise Adaptive Monte Carlo Localization for Humanoid Soccer Robot, Robot, 2012, 6: 652-659, 744.

DOI: 10.3724/sp.j.1218.2012.00652

[9] Duan Rujiao, Zhao Wei, Huang Songling, Chen Jianye, Fast line detection algorithm based on improved Hough transformation, Chinese Journal of Scientific Instrument, vol. 31, no. 12, 2010, pp.2274-2278.

[10] Simon Havkin, Neural Networks and Learning Machines [M]. China Machine Press. 2012: 690-702.

[11] Zhang, X. P. Chen, J. L. Li and X. Li, A vision-based Monte Carlo self-localization system on a walking robot, Robot, vol. 28, no. 4, 2006, pp.415-421.
