The Experimental Study of the Influence of the Foot Articulated Structure on the Biped Robot Walking

Abstract:

Abstract: Purpose：By investigating the variation of the human walking gait kinematics with respect to the foot deformation constraint, prove that bionic design of feet are the necessity for biped robots to imitate human walking better in terms of flexibility, stability and efficiency. The results will be significant for future research and development of biped robots. Methods: A human being was assumed as a perfect biped robot which had ideal motion drive and control. The walking gait parameters of two healthy men with foot deformation unconstrained and constrained were tested respectively by the inertia motion capture suit, and then they were processed by programming and analyzed by comparison. Results: The data analysis showed that when subjects walked with foot deformation constrained, their angular displacements of lower limb joints generally increased, the curves of angular velocity and accelerations fluctuated in certain walking phases, the walking pace and stride length decreased obviously, the single support phase shortened while the double support phase lengthened. At the same time, subjects felt subjectively that their body motion was less flexible, the walking posture was difficult to control, and the walking stability was more strenuous to keep. Conclusion: Combining the logical analogies with the detailed experimentation results, it is inferred that biped robots with rigid feet will have to suffer awkward and unstable walking gait, heavier and strenuous steps, and lower energy efficiency while walking. The paper concludes the necessity of bionic design of the robot feet for improving the walking quality of the biped robots. The conclusion and the experiment data will be of significant value for future work of robot design and evaluation.

• Periodical: Applied Mechanics and Materials (Volume 461)
• Pages: 924-929
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.461.924
• Online since: November 2013
• Authors: Xiao Chun Hu, Xiao Peng Li, Qing Qing Zhang, Bao Zhao, Qin Xia
• Keywords: Biped Robot, Foot Deformation, Kinematics, Structure, Walking Gait

References

[1] Khalaf, Kinda; Hemami, Hooshang. THE PAST AND PRESENT OF HUMAN MOVEMENT RESEARCH: TOWARDS THE DESIGN OF HUMAN-LIKE ROBOTS. Journal of Mechanics in Medicine & Biology. Vol. 12, No. 2, (2012).

DOI: 10.1142/s0219519412400052

[2] Fei Sun, He hua Ju, Ping yuan Cui. A New 12 DOF Biped Robot's Mechenical Design and Kinematic Analysis. 2011 International Conference on Electronic & Mechanical Engineering and Information Technology. Vol. 5, p.2396 – 2400, (2011).

DOI: 10.1109/emeit.2011.6023592

[3] N. Mir-Nasiri, H. Siswoyo Jo. Joint Space Legs Trajectory Planning for Optimal Hip-Mass Carry Walk of 4-DOF Parallelogram Bipedal Robot. Proceedings of the 2010 IEEE International Conference on Mechatronics and Automation. p.616 – 621, (2010).

DOI: 10.1109/icma.2010.5587935

[4] Jianxi Li, Qiang Huang, Weimin Zhang, Zhangguo Yu, and Kejie Li. Flexible Foot Design for a Humanoid Robot. Proceedings of the IEEE International Conference on Automation and Logistics. p.1414 – 1419, (2008).

DOI: 10.1109/ical.2008.4636375

[5] Xiao Le, Zhang Yusheng, Yin Chenbo. Research of Humanoid Robot Biped Walking Model. Computer Engineering. Vol. 37, No. 12, (2011).

[6] Sebastian Lohmeier, Thomas Buschmann, Heinz Ulbrich, Friedrich Pfeiffer. Modular joint design for performance enhanced humanoid robot LOLA. Proceedings 2006 Conference on International Robotics and Automation, pp.88-93. (2006).

DOI: 10.1109/robot.2006.1641166

[7] Sebastian Lohmeier, Thomas Buschmann, and Heinz Ulbrich. System Design and Control of Anthropomorphic Walking Robot LOLA. IEEE/ASME TRANSACTIONS ON MECHATRONICS, Vol. 14, No. 6, p.685– 666 , (2009).

DOI: 10.1109/tmech.2009.2032079

[8] David Tlalolini, Christine Chevallereau, and Yannick Aoustin. Human-Like Walking: Optimal Motion of a Bipedal Robot With Toe-Rotation Motion. IEEE/ASME TRANSACTIONS ON MECHATRONICS, Vol. 16, No. 2, (2011).

DOI: 10.1109/tmech.2010.2042458

[9] Wang Liquan, Yu Zhiwei. Dynamic Simulation of Biped Robot Human-like Walking Based on ADAMS. Computer Simulation. Vol. 36, No. 3, (2009).

[10] Wang Liquan, Yu Zhiwei. Experimental Study and Prototype Development of Biped Robot HEUBR_1. Robot. Vol. 31, No. 5, (2009).

[11] Hu Xiaochun, Zhou Fujing, Hu Zhixing. The Multi-Rigid-Body Modeling and Gait Simulation for Human Foot Kinematics. 2012 The 3rd International Conference on Mechanic Automation and Control Engineering, Vol. 2, pp.1150-1153, (2011).

[12] Ming-Hsun Chiang, Fan-Ren Chang. Anthropomorphic Design of the Human-Like Walking Robot. Journal of Bionic Engineering. Vol 10, No 2, p.186–193, (2013).

DOI: 10.1016/s1672-6529(13)60214-0

[13] Gao Shilian. Practical anatomy atlas limbs fascicule (leg) [M]. Shanghai: Shanghai Science and Technology Publishing Press, (1985).

[14] Wu Ming, Ji Linhong, Jin Dewen, Zhu Qingfeng, Wang Rencheng. Human metatarsophalangeal joints bend effects on walking gait characteristics, Journal of Tsinghua University (natural science edition), Vol. 42, No. 8, (2002).

[15] Qian Jingguang, Song Yawei Ye Qiang. The biomechanics principle of walking and analysis on gait. Journal of Nanjing Institute of Physical Education (natural science edition), Vol. 5, No. 4, p.1– 7, (2006).

[16] A. Biswas, E. D. Lemaire, J. Kofman. Dynamic gait stability index based on plantar pressures and fuzzy logic. Journal of Biomechanics, Vol. 41, No. 7, p.1574– 1581, (2008).

DOI: 10.1016/j.jbiomech.2008.02.009

[17] Kaveh Akbari Hamed, Nasser Sadati. Stabilization of Periodic Orbits for Planar Walking With Noninstantaneous Double-Support Phase. IEEE Transactions on Systems, Man, and Cybernetics Part A: Systems and Humans, Vol. 42, No. 3, p.685– 706, (2012).

DOI: 10.1109/tsmca.2011.2169246
