Finite Element Simulation Analysis of Multi-Stands Three-Roller Cold Rolling Process for Double Metal Composite Seamless Steel Tube

Abstract:

The numerical simulation of the Y-type three-roller two stands cold rolling stainless steel/carbon steel double metal composite seamless steel tube process was conducted through the finite element analysis of the elastic-plastic by applying the MSC.MARC software. Based on the numerical simulation, the character of stress and strain distribution parameters during the Y-type three-roller two stands cold rolling were obtained by the finite element analysis, and acquired the section pass deformation figure. The distribution of the axial stress, circle stress and radial stress were drawn below the Y-type mill along the circle. The mechanism of the tube cold rolling process and the effect of the forming steel tube both the diameter and wall thickness accuracy were explained according to the stress distribution. The results of the research can be applied to the design of the technical parameters in the forming process.

• Periodical: Applied Mechanics and Materials (Volume 470)
• Pages: 197-204
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.470.197
• Online since: December 2013
• Authors: Xian Kang Wang, Jin Duo Ye, Xu Ma, Qian Qian Tian, Xue Li, Yan Bao
• Keywords: Double Metal Composite Seamless Steel Tube, Finite Element Method (FEM), Numerical Simulation, Three-Roller Two Stands Cold Rolling, Y-Type Mill

References

[1] Miguel A. Cavaliere, Marcela B. Goldschmit, Eduardo N. Dvorkin. Finite element analysis of steel rolling process[J]. Computer and structure, 2001, (79): 2075-(2089).

DOI: 10.1016/s0045-7949(01)00055-4

[2] Du Fengshan, Zhou Qingtian, Wu Jian. Computer Simulation of 3-roll Continual Tube Rolling PQF, [J]. Iron & Steel, 1998. 33(8): 35-37.

[3] Yin Yuande, Li Shengdi. The 3-D finite element analysis of steel tube continuous rolling process with multi-stand pipe mill, [J]. heavy machinery, 2005. (4): 39-42.

[4] Zong Jiafu, Zhang Wenzhi, Xu Xiumei, et al. Finite element simulation of reversal cold rolling mill for asymmetrical clad strip, [J]. steel rolling, 2004. (6): 21-25.

[5] Xu Xiumei, Zhang Wenzhi, Zong Jiafu, et al. Investigation on extreme reduction in cold rolling of stainless steel/steel clad sheet based on FE simulation, [J]. heavy machinery, 2003. (6): 21-25.

[6] N. D. Lukaschkin, A. P. Borissow. Interface surface behaviour in the upsetting of sandwich metal sheets[J]. Journal of Materials Technology, 1996, (61): 292-297.

DOI: 10.1016/0924-0136(95)02183-3

[7] Haimiao Wu, Guiying Yao, Yanwei Zhang, et al. Research into Edge Drop of Cold Rolled Strip and Its Influencing Factors[C]. 2010 Second International Conference on Computer Modeling and Simulation, 2010, (48): 152-154.

DOI: 10.1109/iccms.2010.48

[8] Pei-feng Hao. The structure and function of computer control simulation system in cold mill[J]. Journal of Northeastern University: Natural Science, 2001, 22(6): 639-642.
