Development of Machine Vision Positioning System of Magnetorheological Fluid (MRF) Actuator

Abstract:

Magnetorheological valve offers several advantages such as controllability, small in size and no moving part during operation. Thus, many researchers are working on developing an actuator based on this valve. However, this actuator required feedback system to improve it precision. This research is focusing on developing of machine vision based positioning system for MRF actuator. Image processing algorithms coded using Matlab software and directly connect to MRF valve controller. As a result, the system shows a fast response with processing time only 0.6 millisecond, system resolution is 0.1 millimeter and finally repeatability is 0.01. As a conclusion, the machine vision system are applicable for MRF actuator positioning system. This study is significant in order to developing a low cost and robust positioning system.

• Periodical: Applied Mechanics and Materials (Volume 470)
• Pages: 625-629
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.470.625
• Online since: December 2013
• Authors: A.B. Husaini, Ghazali Izzat, Samad Zahurin, Othman Rusli
• Keywords: Hydraulic, Machine Vision, Magnetorheological Fluid, Positioning System, Repeatability

References

[1] Ai, H. X., Wang, D. H. and Liao, W. H. : Design and Modelling of a Magnetorheological Valve with Both Annular and Radial Flow Path (Journal of Intelligent Material Systems and Structures, Vol. 17, p.327, 2006).

DOI: 10.1177/1045389x06055283

[2] John, S., Chaudhuri A. and Wereley N. M. (2008) A magnetorheological actuation system: test and model, Smart Materials and Structures, Vol. 17 , p.25023 – 25038.

DOI: 10.1088/0964-1726/17/2/025023

[3] Anderson, Eric H., Cash, Michael, F., Evert, Michael, E. and Pendleton, Scott, C., Magnetorheological Fluid Damper with Integral Step and Repeat Actuator, World Scientific Pub Co Inc. p.368, (2008).

DOI: 10.1142/9789812771209_0052

[4] Salloom, M. Y. and Samad, Z., (2011) Finite element modeling and simulation of proposed design magneto-rheological valve, The International Journal of Advanced Manufacturing Technology, Vol. 54 p.421–429.

DOI: 10.1007/s00170-010-2963-1

[5] Hammouda, Laroussi; Mekki, Hassen; Kaaniche, Khaled; Chtourou, Mohamed, Improving mobile robot robustness in visual servoing application, Systems, Signals & Devices (SSD), 2013 10th International Multi-Conference on , vol., no., p.1, 6, 18-21 March (2013).

DOI: 10.1109/ssd.2013.6564131

[6] Fahimi, Farbod; Thakur, Karansingh, An alternative closed-loop vision-based control approach for Unmanned Aircraft Systems with application to a quadrotor, Unmanned Aircraft Systems (ICUAS), 2013 International Conference on , vol., no., p.353, 358, 28-31 May (2013).

DOI: 10.1109/icuas.2013.6564708

[7] Fomena, Romeo Tatsambon; Quintero, Camilo Perez; Gridseth, Mona; Jagersand, Martin, Towards Practical Visual Servoing in Robotics, Computer and Robot Vision (CRV), 2013 International Conference on , vol., no., p.303, 310, 28-31 May (2013).

DOI: 10.1109/crv.2013.23
