Strain Measurement for Sheet Metal Forming Based on Close Range Photogrammetry

Abstract:

To improve efficiency and automation of the 3D full-field surface strain measurement for sheet metal forming, a new grid strain measuring scheme was developed based on the close-range photogrammetry technology. A Local Canny Detector algorithm was proposed for grid nodes and coded targets detection. A 10-parameters nonlinear camera model and the bundle adjustment algorithm were used to optimize the calibration parameters. A multi-epipolar constraint method was employed for grid node matching. Finally, the surface strains were calculated according to the changes of the grid sizes. To evaluate the performance of the proposed scheme, a stamping forming experiment was conducted. Experimental results show that the scheme can provide a non-contact, intuitive and effective solution for strain measurement in sheet metal forming process.

• Periodical: Applied Mechanics and Materials (Volumes 475-476)
• Pages: 148-155
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.475-476.148
• Online since: December 2013
• Authors: Da Cheng Li, Jin Liang, Hao Hu*, Zheng Zong Tang, Xiang Guo, Lei Gang Li
• Keywords: 3D Grid Generation, Grid Node Matching, Sheet Metal Forming, Strain Measurement, Target Detection

References

[1] Xueshan Lu, Xianjin Wang, Yanda Miao. Sheet metal forming and manufacturing (China supplies Publishing, Beijing, 1993) (In Chinese).

[2] Sklad MP. Journal of Materials Processing Technology, Vol. 145-3(2004), pp.377-384.

[3] Ayres RA, Brewer EG, Holland SW. Society of Automotive Engineers Transactions, Vol. 88- 3 (1979), pp.2630-2634.

[4] Bednarski T. International Journal of Mechanical Sciences, Vol. 11-12(1969), pp.949-950.

[5] Orteu J-J, Garric V, Devy M. Proceedings of SPIE, Vol. 3101 (1997), pp.252-263.

[6] Chan H-L, Spence AD, Sklad MP. International Journal of Machine Tools and Manufacture, Vol. 47(2007), pp.191-203.

[7] Canny JF. A computational approach to edge detection (Morgan Kaufmann Publishers Inc., 1987).

[8] Mai F, Hung YS, Zhong H, et al. Pattern Recogn, Vol. 41(2008), pp.2512-2524.

[9] T. Luhmann, S. Robson, S. Kyle, et al. Close Range Photogrammetry: Principles, Techniques and Applications (Whittles Publishing: London, 2006).

[10] Information on http: /wwwvisioncaltechedu/bouguetj/calib_doc.

[11] Hao Hu, Jin Liang, Zhengzong Tang, et al. Optics and Precision Engineering, Vol. 2(2012), pp.369-378. (In Chinese).

[12] Tang Z-Z, Liang J, Xiao Z-Z, et al. Optical Engineering, Vol. 49-10(2010), p.103601.

[13] Zhang D-h, Liang J, Guo C, et al. Optical Engineering, Vol49-3(2010), p.037005.
