Fault Diagnosis of Analog Circuits with Tolerance Based on Simulation-before-Test and Distance Algorithm

Abstract:

Fault dictionary is the most practical method of fault diagnosis in analog circuit. Before analog circuit with tolerance is diagnosed, circuit is simulated by computer. Typical parameters of every state are used to build fault dictionary. Distance algorithm is used to calculate the similarity between current circuit and every state of fault dictionary. Analog circuit with tolerance can be diagnosed by the distance. Firstly, the method of simulation-before-test is introduced to build fault dictionary. Secondly, familiar distance algorithm is resumed, such as Euclidean distance. Finally, an example of fault diagnosis of analog circuit with tolerance is provided. In the example, simulation-before-test and distance algorithm are combined to diagnose analog circuit with tolerance. Two distance methods are compared to explain the advantages and disadvantages of the Euclidean distance algorithm.

• Periodical: Applied Mechanics and Materials (Volumes 475-476)
• Pages: 156-160
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.475-476.156
• Online since: December 2013
• Authors: Yong Jie Zhang*, Jian Jun Hou, Liang Huang
• Keywords: Analog Circuit, Euclidean Distance, Fault Diagnosis, Fault Dictionary, Simulation before Test

References

[1] Peng Wang, Shiyuan Yang: A New Diagnosis Approach for Handling Tolerance in Analog and Mixed-signal Circuits by Using Fuzzy Math (IEEE Transactions on Circuits and Systems I: Fundamental Theory and Applications, Piscataway, NJ, 2005).

DOI: 10.1109/tcsi.2005.853266

[2] Halgas Stanisaw: Multiple Soft Fault Diagnosis of Nonlinear circuits Using the Fault Dictionary Approach (Bulletin of the Polish Academy of Sciences: Technical Sciences, Poland, 2008).

[3] Vladimir N Vapnik: An Overview of Statistical Learning Theory (IEEE Transaction On Neural Network, USA , 1999).

[4] Zhang Yi, Wei Xueye and Jiang Haifeng: One-class Classifier Based on SBT for Analog Circuit Fault Diagnosis (Measurement, England, 2008).

DOI: 10.1016/j.measurement.2007.02.007

[5] Huang Liang: Grey entropy relation algorithm of selecting the optimum testing nodes in analog circuits (Chinese Journal of Electronics, Beijing, 2013).
