Research on Hexahedral and Tetrahedral Mesh Applied to Strength Analysis of Bogie Frame

Abstract:

The structure of bogie frame is meshed by hexahedral and tetrahedral elements respectively. FE analysis is taken based on the loads defined by JIS E 4207 standard and the stress distributions of two separate models are obtained. To clarify the accuracy of two kinds of finite element models, the bench test of the bogie frame is carried out. It shows that both the hexahedral and tetrahedral models are valid according to the comparison between FE results and experimental values when the structural model is regular. However, for complex structure model 10-node tetrahedral model takes precedence.

• Periodical: Applied Mechanics and Materials (Volumes 477-478)
• Pages: 150-154
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.477-478.150
• Online since: December 2013
• Authors: Guang Jun Li, Wen Jing Wang, Li An, Ze Jin Zhang
• Keywords: Bogie Frame, Finite Element Analysis (FEA), Hexahedral, Tetrahedral

References

[1] Jun Lu, Zhongjin Wang and Zhongren Wang: Generation of Finite Element Hexahedral Mesh and Its Wend of Development. Journal of Harbin Institute of Technology Vol. 33-4 (2001), pp.485-490 (In Chinese).

[2] Dan Li, Can Jin and Xiaoping Liu: Present Situation of Research on Finite Element All-hex Mesh Generation Methods.  Microcomputer Application Technology Vol. 77 (2010), pp.1-6 (In Chinese).

[3] Rong Zhang: Comparison of Tetrahedral and Hexahedral Mesh. Technological Development of Enterprise Vol. 31-27 (2012), pp.101-102 (In Chinese).

[4] Sulei Tian, Zhiyi Zhang and Min Chen: Research and Implementation of Methods for Tetrahedral Mesh Generation. Computer Engineering and Design Vol. 33-1 (2012), pp.4416-4421 (In Chinese).
