Dynamic Response Analysis of Square Honeycomb Sandwich Plates Subjected to Blast Loading

Abstract:

The dynamic response of the square honeycomb sandwich plates subjected to blast loading was simulated and analyzed by using the finite element software ABAQUS.With the given mass per unit area,core sheet spacing and height,the optimal relative density of the core was obtained under blast loading of three levels.With this optimal relative density,the sandwich plates have the best shock resistance ability and the top and bottom face sheets have the smallest deflection subjected to impulsive load.The sandwich plates were compared with the solid plates having the same mass per unit area.The results show that the sandwich plates have higher strength and energy absorption capability.Furthermore,influence of geometrical parameters including core sheet spacing,thickness,height and face sheet thickness on the face sheetss maximum deflection were discussed.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 477-478)

Pages:

160-164

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.477-478.160

Citation:

Cite this paper

Online since:

December 2013

Authors:

Lei Deng*, An Wen Wang, Liu Wei Mao

Keywords:

Blast Loading, Dynamic Response, Finite Element (FE) Simulation, Sandwich Plates

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Z.Y. Xue, J.W. Hutchinson: International Journal of Mechanical Sciences Vol. 45 (2003), P. 687-705.

Google Scholar

[2] Z.Y. Xue, J.W. Hutchinson: International Journal of Impact Engineering Vol. 30 (2004), P. 1283-1305.

Google Scholar

[3] J.W. Hutchinson, Z.Y. Xue: International Journal Mechanical Sciences Vol. 47 (2005), P. 545-569.

Google Scholar

[4] Z.Y. Xue, J.W. Hutchinson: International Journal for Numerical Methods in Engineering Vol. 65 (2006), P. 2221-2245.

Google Scholar

[5] N.G. Wadley, K.P. Dharmasena, et al: Journal of Mechanics of Materials and Structures Vol. 2 (2007), P. 2025-(2048).

Google Scholar

[6] G.J. Mcshane, V.S. Deshpande, et al: International Journal of Impact Engineering Vol. 37 (2010), P. 1138-1149.

Google Scholar

[7] K.P. Dharmasena, N.G. Wadley, et al: International Journal of Impact Engineering Vol. 38 (2011), P. 275-289.

Google Scholar

[8] K.P. Dharmasena, N.G. Wadley, et al: International Journal of Impact Engineering Vol. 35 (2008), P. 1063-1074.

Google Scholar

[9] ABAQUS/Explicit User's Manual.

Google Scholar
