Identifying the Unit Area Dynamic Characteristic Parameters of Fixed Joint Based on Equivalent Single DOF System

Abstract:

A whole machine tool structure is a muti-DOF system, it is usually composed of many parts which are connected with joint interfaces. The structure is complicated that the accuracy of modal test is always in a low level. When doing modal test, equivalent single DOF method can not only improve the efficiency and decrease the difficulty, but also exclude interferences such as random noise. In this paper, the author simplified a two-DOF system into an equivalent single DOF system and derived its frequency response function, then analyzed a testing device for fixed joint by using the equivalent single DOF method, and measured several groups of unit area dynamic characteristic parameters of fixed joint interfaces in different materials and different working conditions. The dynamic characteristic parameters can be used in further study of machine tool joint interfaces.

• Periodical: Applied Mechanics and Materials (Volume 483)
• Pages: 322-325
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.483.322
• Online since: December 2013
• Authors: Yi Chuan Xiao*, Liang Sheng Wu, Jian Feng Ma, Hao Hong
• Keywords: Equivalent Single Degree System, Frequency Response Function, Joint, Unit Area Dynamic Characteristic Parameters

References

[1] M. Yoshimura. Computer-aided design improvement of machine tool structure incorporating joint dynamics data. Annals of CIRP. 1979, 28(1): 241-246.

[2] Zhang Xueliang, Xu Gening, Wen Shuhua, Review and Prospect of the research on the static and dynamic characteristics of machine jiont surfaces, Journal of TaiYuan Heavy Machinery Institude, Vol. 23, pp.276-279, Sep. 2002 (In Chinese).

[3] Hongliang Tian, Bin Li, Hongqi Liu, Kuanmin Mao, Fangyu Peng, Xiaolei Huang . A new method of virtual material hypothesis-based dynamic modeling on fixed joint interface in machine tools International Journal of Machine Tools & Manufacture 51 (2011).

DOI: 10.1109/icmet.2010.5598455

[4] T. Inamura, T. Sata. Stiffness and damping properties of the elements of a machine tool structure. Annals of the CIRP. 1979, 28: 235-239.

[5] Xiao Yichuan, Research on dynamic characteristic of the assembled structure of beams considering characteristic of joint [D], Beijing University of technology, 2010(in Chinese).

[6] T. Inamura, T. Sata. Stiffness and damping properties of the elements of a machine tool structure. Annals of the CIRP. 1979, 28: 235-239.

[7] C. P. Fritzen. Identification of Mass, Damping and Stiffness Matrices of Matrices of Mechanical Systems. ASME Journal of Vibration, Acoustics, Stress and Reliability in Design. 1986, 18: 9-16.

DOI: 10.1115/1.3269310

[8] XiaoYichuan, WuLiangsheng. Research on dynamic characteristics of the assembled beams. ICEICE 2011 - Proceedings, pp.3502-3505, (2011).

DOI: 10.1109/iceice.2011.5778296
