The Numerical Simulation of Hemispherical Parts Based on FBDF Technology

Abstract:

in this paper, we mainly introduce the principle of the flexible blank drawer forming (FBDF), and establish the limited element model of the FBDF process. Then we make a numerical analysis on the hemispherical parts, and study the effect made on the result of shaping by damping force, friction coefficient as well as material parameter in per unit area. Through the analysis of the numerical simulation result, we can conclude that the greater the yield limit and elasticity modulus, the larger blank drawer force is required to form the shape; the more smooth the material surface, the less resistance to deformation will have. All this contributes to good quality of forming parts.
