Study of Temperature Field Distribution and Deformation of Chain Link Based on Pro/E

Abstract:

This paper studies the temperature field variation of the chain link as well as the stress and deformation distribution of the pin which works in hot forging and stamping production line with heat recovery function. The approach is to build the model of the chain link with Pro/Engineer and apply it to the simulation with Pro/Mechanica. To be specific, it is to stimulate the thermal conduction of the chain link and the stress state of the pin under high temperature with Pro/Mechanica-Thermal and Pro/Mechanica-Structure module, respectively. The results are the temperature filed nephogram of the chain link as well as the stress and deformation nephogram of the pin. The simulation shows that:1) the temperature reaches 420°C at the contacts of the outer and inner plates at 600s, 2) the maximum stress of the pin is 112Mpa at the ends where the pin meets the outer and inner plates,3) the pins max deformation is 0.0159mm at the middle of the pin. Comparing the simulation to the actual temperature at the contacts of the outer and inner plates,which is measured ten times in advance with average of 439°C ,the simulation is favorable. According to the results above, graphite lubrication should be chosen for the chain and the pin can work properly with deformation rate of 0.795. By this way of simulating with Pro/Mechanica, complicated calculations and repeated tests can be reduced largely, meanwhile, useful parameters and mathematical model can also be provided for manufacturing and process control.

• Periodical: Applied Mechanics and Materials (Volumes 490-491)
• Pages: 836-840
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.490-491.836
• Online since: January 2014
• Authors: Bing Ma*, Li Zhen Liu, Xue Feng Bai, He Wang, Li Wei Yang, Chong Wang, Shi Nan Li, Lu Ning Yu, Hui Chen
• Keywords: Chain Link, Pro/MECHANICA, Temperature Field, Thermodynamics Analysis

References

[1] Lan Hongkui, LI Yan, Shu Guangyangzi: An overview of domestic Technologies for Waster Heat Utilization. Energy Conservation Technology, vol. 29, n. 166 (2011 ), pp.123-128.

[2] Inoue, Naoyuki: Absorption heat pumps for low-temperature waste heat recovery. Nihon Enerugi Gakkaishi/Journal of the Japan Institute of Energy, vol. 88, n. 11 (2009), pp.979-985.

[3] Chen Hui，Chen lili，Qin panpan，Yu luning，Liu shikui: Analysis of the thermal parameters in the production of 58SiMn steel based on waste heat recovery technology of heat pump. Journal of Shenyang Jianzhu university natural science, vol. 27, n. 5 (2011).

DOI: 10.1109/icetce.2011.5776430

[4] Soylemez M S: Optimum heat pump in drying systems with waste heat recovery. Journal o f Food Engineering, vol. 74, n. 3 (2006), pp.292-298.

DOI: 10.1016/j.jfoodeng.2005.03.020

[5] Ju Zhilan, Hua Guoran, Chen Houjun: Thermal and MechanicalAnalysis of Piston Using 3D Finite Element Method Based on Pro/Mechanica. Small Internal Combustion Engine and Motorcycle, vol. 39, n. 3 (2010), pp.9-12.

[6] Ye Yan, Liu Qiang, Yuan Songmei, Liu Jingwei: Finite Element Analysis on Thermal Characteristics of Spindle System in Gantry Type Machining Center. Machine Tool Design and Research, Vol. 2 (2007), pp.32-35.

[7] Meggers Forrest, Leibundgut Hansjurg: The potential of wastewater heat and exergy: Decentralized high-temperature recovery with a heat pump. Energy and Buildings, vol. 43, n. 4 (2011), pp.879-886.

DOI: 10.1016/j.enbuild.2010.12.008

[8] Yu Mi: Thermodynamics Analysis of the Body of High Pressure Valve Based On Pro/Mechanica. Heat Processing Technology and Material Research, Vol. 4 (2008), pp.68-70.

[9] Zhang Tiejun: Mechanical Engineering Materials (Peking university press, Beijing 2010), pp.138-139.

[10] Chen Yirui: Basic materials and new materials(Tianjin university press, Tianjin 2010), pp.48-50.

[11] Gu Zhuoming: Marine engineering materials(China communication Press, Beijing 2010), pp.58-62.

[12] Xu Xiaohong: Foundations of Materials Science and Engineering(Higher Education Press, Beijing 2008).

[13] The second Longzhen studio: Pro/MECHANICA Wildfire 3. 0/4. 0 Structure/Thermal Analysis(Electronic Industry Press, Beijing 2008), p.158.

[14] Li Gangjun, Tang Jianbing: Machine design foundation(Tsinghua University Press, Beijing 2010 ), pp.78-79.
