Performance of Hydrostatics Spindle under Effect of Mass Unbalance

Abstract:

The static and dynamic model of spindle system is established in order to analyze the vibration response with the effect eccentricity of spindle. Natural frequency of spindle is calculated with ANSYS software. The variation of thickness and stiffness of oil film are analyzed, and the dynamic response is deduced. The deflection of spindle i.e. the machining error caused by the eccentricity is obtained. Key words: Hydrostatic bearings; Dynamic response; Stiffness; Deflection

• Periodical: Applied Mechanics and Materials (Volumes 490-491)
• Pages: 910-913
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.490-491.910
• Online since: January 2014
• Authors: Dong Ju Chen*, Yan Hua Bian, Jin Wei Fan, Fei Hu Fan
• Keywords: Deflection, Dynamic Response, Hydrostatic Bearings, Stiffness

References

[1] Jong-Duk Moon, Bong-Suk Kim, Soo-Hun Lee, Development of the active balancing device for high-speed spindle system using influence coefficients, Int. J. Machine Tools@Manu., vol. 46, 2006, pp.978-987, doi: 10. 1016/j. ijmachtools. 2005. 07. 048.

DOI: 10.1016/j.ijmachtools.2005.07.048

[2] A. B. Jones. A general theory for elastically constrained ball and radial roller bearings under arbitrary load and speed conditions, ASME J Eng Power, vol. 105, 1960, pp: 309-320.

DOI: 10.1115/1.3662588

[3] F. P. Wardle, S. J. LaceyACEY, S. Y. Poon, Dynamic and static characteristics of a wide spread range machine tool spindle, Precision Engineering, vol. 1, October, 1983, pp: 175-183, doi: 10. 1016/0141-6359(83)90097-1.

DOI: 10.1016/0141-6359(83)90097-1

[4] C. H. Chen, K. W. Wang, Y. C. Shin, An integrated approach toward the dynamic analysis of high-speed spindles, Part II：Dynamics under moving end load, International Journal of Vibration and Acoustics, vol. 116, October, 1994, pp: 506-522, doi: 10. 1115/1. 2930457.

DOI: 10.1115/1.2930457

[5] J. G. Bollinger, G. Geiger. Analysis of the static and dynamic behavior of lathe spindle, Int. J. Mach Tool Des, vol. 3, Aprial, 1964, pp: 193-209, doi: 10. 1016/0020-7357(64)90010-1.

DOI: 10.1016/0020-7357(64)90010-1

[6] R. L. Fruhl, J. F. Booker. A finite element model for distributed parameter turborotor systems, J. Eng. Ind, vol. 94, 1972, pp: 128-132, presented at the Vibrations Conference, Toronto, Canada, September 8-10, (1971).

DOI: 10.1115/1.3428101

[7] Y. Z. Cao, Y. Altintas, Modeling of spindle-bearing and machine tool system for virtual simulation of milling operations, International Journal of Machine tools & Manufacture, vol. 47, July, 2007, pp: 1342-1350, doi: 10. 1016/j. ijmachtools. 2006. 08. 006.

DOI: 10.1016/j.ijmachtools.2006.08.006
