Modeling, Prototyping and Testing of Regenerative Electromagnetic Shock Absorber

Abstract:

It is well fact known that automobiles are inefficient, wasting over 74% of energy stored in fuel as a heat. One important loss is the dissipation of vibration energy by shock absorbers in the vehicle suspension under the excitation of road irregularity and vehicle acceleration or deceleration. In this paper we design, characterize and test a regenerative electromagnetic shock absorber which can effectively recover the vibration from the road irregularity. Regeneration energy is main purpose of the design without omit vehicle comfort and handling. The dynamic model of the entire system of the electromagnetic shock absorber was proposed and described. The performance of the electric shock absorber obtained from simulations was compared toward the experiment results. Refers to the simulation, a quarter car will be able to harvest 45 Watt average power while passing C class roads with 50 km/h vehicle speed. A peak power of 45 Watt and average power of 11.43 Watt are attained from the prototype when oscillating speed of bench test at 0.1 m/s, the RMS value of suspension velocity when vehicle pass C class road with speed 50 km/h.

• Periodical: Applied Mechanics and Materials (Volume 493)
• Pages: 395-400
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.493.395
• Online since: January 2014
• Authors: Arif Indro Sultoni, I Nyoman Sutantra, Agus Sigit Pramono
• Keywords: Electromagnetic Generator, Harvesting Energy, Shock Absorber, Vehicle Vibration

References

[1] Lei Zuo, Brian Scully, Jurgen Shestani and Yu Zhou, Design and characterization of an electromagnetic energy harvester for vehicle suspensions , Smart Material and Structure (2010) IOP Publishing, 1-10.

DOI: 10.1088/0964-1726/19/4/045003

[2] Zhen Longxin, Wei Xiaogang, Structure and Performance Analysis of Regenerative Electromagnetic Shock Absorber, Journal of Networks, Vol. 5, (2010), 1467-1474.

[3] S P Beeby, R N Torah, M J Tudor, P Glynne-Jones, T O'Donnell, C R Saha and S Roy, A micro electromagnetic generator for vibration energy harvesting, Journal Of Micromechanics And Microengineering IOP Publishing , UK (2007), 1257-1265.

DOI: 10.1088/0960-1317/17/7/007

[4] D. Mammosser, E. Foltête M. Collet Scavenging energy from a vibrating beam using an electromagnetic transducer, 12th IFToMM World Congress, Besançon (France), (2007).

[5] Kimihiko Nakano, Yoshihiro Suda, Shigeyuki Nakadai, Self-powered active vibration control using a single electric actuator, Journal of Sound and Vibration (2007), 213–235.

DOI: 10.1016/s0022-460x(02)00980-x

[6] Ammar A. Aldair, and Weiji J. Wang, The Energy Regeneration Of Electromagnetic Energy Saving Active Suspension In Full Vehicle With Neurofuzzy Controller, International Journal of Artificial Intelligence & Applications. Vol. 2, No. 2 (2011).

DOI: 10.5121/ijaia.2011.2203

[7] Anil Shirahatt, P.S.S. Prasad, Pravin Panzade, M.M. Kulkarni, Optimal Design of Passenger Car Suspension for Ride and Road Holding, J. of the Braz. Soc. of Mech. Sci. & Eng, Vol. XXX (2008), 67-76.

DOI: 10.1590/s1678-58782008000100010

[8] Babak Ebrahimi, Development of Hybrid Electromagnetic Dampers for Vehicle Suspension Systems, Ph. D Thesis, Mechanical Engineering Dept, Univ. waterloo, Ontario, Canada (2009).

[9] ISO: 2631-1, 1997, Mechanical vibration and shock - Evaluation of human exposure to whole-body vibration.

[10] Information on : http: /forums. carmudgeons. com/showthread. php?t=21901.

[11] Lei Zuo, Pei Sheng Zhang, Energy Harvesting, Ride Comfort, and Road Handling of Regenerative Vehicle Suspension, Journal of Vibration and Acoustic, 135, (2013) 011002-1 – 011002-8.

DOI: 10.1115/1.4007562
