A Method for Extracting Acoustic Emission Signal Frequency Characteristics of Polluted-Insulator Discharge

Abstract:

Experimental studies have shown that Acoustic Emission (AE) signals generated by the polluted-insulator discharge contain information of discharge energy. To extract the frequency characteristics of AE signals in polluted-insulator discharge, algorithm combining the empirical mode decomposition (EMD) and fast fourier transform (FFT) is used. Through a great many of artificial contamination experiments, the AE signals in different contamination discharge stages are collected, and the frequency characteristics can be extracted by the method presented in this article. The results show that the frequency characteristics of AE signals can be effectively extracted by the proposed method, which gives the right corresponding relationship between frequency characteristics and the polluted-insulator corona, partial and arc discharge. It also provides technical support for monitoring the intensity of polluted-insulator discharge and the change of external insulation status. The method for extracting AE signal frequency characteristics proposed in this paper has been applied to on-line monitoring of polluted-insulator external insulation status and good results have been achieved.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 1513-1516
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.1513
• Online since: February 2014
• Authors: Man Cheng Yi*, Jian Fang, Yong Wang, Zhi Ning Li, Chun Hui Gu, Nai Qiu Shu, Zi Pin Li
• Keywords: Acoustic Emission Signal, Empirical Mode Decomposition (EMD), Fast Fourier Transform, Frequency, Polluted-Insulator Discharge

References

[1] Wardman, J. , Wilson, T. , Bodger, P. Volcanic ash contamination: limitations of the standard ESDD method for classifying pollution severity. Dielectrics and Electrical Insulation, IEEE Transactions on Vol. 20 ,  No. 2 , April (2013).

DOI: 10.1109/tdei.2013.6508742

[2] D. Devendranath, G. Girija, R.S. Shivakumara Aradhya, B. Gunasekaran. Development and application of a multi channel current integrator-cum-peak classifier for online monitoring of leakage current on RTV coated insulators. IEE Proc. -Gener. Transm. Distrib., Vol. 152, No. 2, March 2005: 247-252.

DOI: 10.1049/ip-gtd:20040735

[3] Weigen Chen, Chenguo Yao, Pan Chen, etc. A New Broadband Microcurrent Transducer for Insulator Leakage Current Monitoring System. IEEE TRANSACTIONS ON POWER DELIVERY, VOL. 23, NO. 1, JANUARY 2008: 355-360.

DOI: 10.1109/tpwrd.2007.905833

[4] Anders Larsson, Albin Roslund, Stefan Kroll, Andreas Dernfalk. In-situ diagnostics of HV outdoor insulators using laser-induced fluorescence spectroscopy. IEEE Transactions on Dielectrics and Electrical Insulation, VOL. 9, NO. 2, April 2002: 274-281.

DOI: 10.1109/94.993745

[5] LI Zipin，SHU Naiqiu，LI Hongling, WANG Youyin. Acoustic Emission Diagnosis Method of Insulator's Pollution Discharge Based on Kernel Principle Component Analysis[J]. High Voltage Engineering，2012, 38(11)：3008-3014.

DOI: 10.1109/peam.2012.6612502

[6] Huang N E, Shen Zheng. The Empirical Mode Decomposition and the Hilbert Spectrum for Nonlinear and Non-Stationary Time Series Analysis. Proe.R. Soc. London. A454, 1998: 903一995P.

[7] Loh CH., Wu TC., Huang N E. Application of Empirical Mode Decomposition-Hilbert Spectrum Method to Identify Near-fault Groundmotion Characteristics and Structural Responses. Bulletin of the seismological Society of America. 2001, 91(5): 1339-1357P.

DOI: 10.1785/0120000715

[8] Huang N E, Wu Man-Li, Qu Wen-dong, ed. Applications of Hilbert-Huang Transform to Non-stationary Financial Time Series Analysis. Appl. Stochastic Models Bus. Ind. 2003, 19 (361): 245-268P.

DOI: 10.1002/asmb.501

[9] R Hlike. A Study on Empirical Mode Decomposition. [Dissertation]. Univ. of Amsterdam. (2002).
